820-20

INIATURE MINIATURE FUSEHOLDERS Holder / No. 820-20 820-20 Panel Mount, Shocksafe 5x20mm Fuses Fuse carrier inserted max. 0,2 M12,7x1,5 Specifications Packaging 0 bulk (100 pcs.) Standard IEC 60127-6 UL 512 4,45 0,5 Approvals (only 820/835) 7,62 Mounting Bayonet-joint 3,2 2,5 12.7mm diameter D-hole or double D-hole Admissible torque on plastic hex nut is 1.2Nm Solderable or 4.8mm quick connect-fits 0.5mm tab IP 40 (IEC 60529) PC2 (IEC 60127-6) Holder/Cap: Metal Parts: Terminals: Nut: Te r m i n a l s SW14 ∅15 ∅16 11,7 -0,15 12 -0,1 4,8 Protection Class & Category Materials 5,5 1...6 5 32 8 12,7 -0,1 12,7 -0,1 Panel alternatives White Thermoplastic PBT, UL94 V-0 Copper alloy, corrosion protected Solderable, tinned Thermoplastics, Polyamid PA 6.6, black, UL94 V-0 Electrical Data (23ºC) Rated Voltage: 250V Rated Current: 6.3A (VDE/SEMKO) 16A (UL) Rated Power: 2.5W (SEMKO) -25ºC to +70ºC (consider de-rating) -25ºC/+70ºC/21 days (IEC 60068-2-1...3) +10ºC to +60ºC relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% 24 cycles at 15 min. each (IEC 60068-2-6) 10 - 60Hz at 0.75mm amplitude 60 - 2000Hz at 10g acceleration ≤ 5mΩ Operating Temperature Temperature Test Climatic Test Cap / No. 835-20 Bayonet-connector-nose max. 20,6 1,5 Stock Conditions Vibration Resistance ∅ 9,2 Contact Resistance 1,2 7 Dielectric Strength > 1.5 kV Type Flush Mount Type Slot for screwdriver Impulse Voltage 4 kV with 1,2µs/50µs > 10 MΩ ( 500 VDC, 1 min.) 235 ºC, 2 sec. (soldering bath) (IEC 60068-2-20) 350 ºC, 3 sec. (soldering iron) (IEC 60068-2-20) 260ºC, 5 sec. (IEC 60068-2-20) Conductor - 2.5mm 2 Insulation Resistance Solderability Soldering Heat Resistance Minimum Cross Section Marking 820, 250V, Approvals 4.0g (820) / 1.6g (835) Order Info Qty. Order Number Series Unit Weight 0000 02 Packaging 0 Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand. In our continuing strategy to deliver unparalleled circuit protection solutions, technical expertise and application leadership, we proudly introduce the WICKMANN Group and its products to the Littelfuse portfolio. Specifications are subject to change without notice 0 50906 WebSite www.littelfuse.com
