835-20

INIATURE MINIATURE FUSEHOLDERS Holder / No. 824-20 Panel Mount for 5x20mm Fuses Einsatzträger eingesetzt fuse-carrier inserted ø15 Renkverschluß bayonet-joint Überstand distance Specifications Standard IEC 60127-6 UL 512 CSA C22.2. No.39 5,5 1,2...2,5 2,5 ø12,72 +0,1 Gerätewand (Kunststoff) panel mounting (thermoplastic) 32 11 max. 0,2 Mounting ø11,7 Pluggable (panel thickness 1.2 mm-2.5 mm) Solderable or 4.8mm quick connect - fits 0.5mm tab IP 40 (IEC 60529) PC2 (IEC 60127-6) Te r m i n a l s 4,45 2,5 3,2 8 R1 0,5 Protection Class & Category Materials 4,8±0,1 P. 7,62±0,1 Ø12,7 -0,05 Panel mounting hole Holder/Cap: Thermoplastic (Polyamide PA 6.6), UL94 V-0, black Metal Parts: Copper alloy, corrosion protected Terminals: solderable tinned Rated Voltage: Rated Current: Rated Power : 250V 6.3A (VDE/SEMKO) 16A (UL/CSA) 4W (VDE/SEMKO) Cap / No. 835-20 Slot for screwdriver ∅ 9,2 Bayonet-connector-nose Electrical Data (23ºC) 1,5 Temperature Operating Temperature max. 20,6 -25ºC to +70ºC (consider de-rating) -25ºC/+70ºC/21 days (IEC 60068-2-1...3) +10ºC to +60ºC relative humidity ≤ 75% yearly average, without dew, maximum value for 30 days - 95% 24 cycles at 15 min. each (IEC 60068-2-6) 10 - 60Hz at 0.75mm amplitude 60 - 2000Hz at 10g acceleration ≤ 5mΩ Test Climatic Test Stock Conditions 7 Type Flush Mount Type 1,2 Vibration Resistance Contact Resistance Dielectric Strength > 1.5 kV Voltage Impulse Voltage 4 kV, 50Hz, 1 min., dry > 10 3 MΩ ( 500VDC, 1 min.) 235ºC, 3 sec. (Wave) 350ºC, 1 sec. (soldering iron) 260ºC, 5 sec. (IEC 60068-2-20) Conductor - 2.5mm 2 Insulation Resistance Solderability Order Information Packaging Bulk (100 pcs.) Holder Cap, Flush Mount No. 824 2000 000 No. 835 2000 000 Soldering Heat Resistance Minimum Cross Section Marking Order Numbers 824, 250V, Approvals 3.3g (824) / 1.6g (835) / 2.2g (837) Unit Weight Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand. 0 50909 In our continuing strategy to deliver unparalleled circuit protection solutions, technical expertise and application leadership, we proudly introduce the WICKMANN Group and its products to the Littelfuse portfolio. WebSite www.littelfuse.com
