FM401 thru FM407
Surface Mount Glass Passivated Junction Rectifiers
Reverse Voltage 50 to 1000V Forward Current 1.0A
FEATURES
* Plastic package has Underwriters Laboratory
Flammability Classification 94V-0
* High temperature metallurgically
bonded construction
* Cavity-free glass passivated junction
* Capable of meeting environmental standards
of MIL-S-19500
* Typical IR less than 1.0µA
* High temperature soldering guaranteed:
260°C/10 seconds
Mechanical Data
Case: JEDEC DO-214AC, molded plastic over glass body
We declare that the material of product compliance
Terminals: Plated axial leads, solderable per
with ROHS requirements
MIL-STD-750, Method 2026
Polarity: Color band denotes cathode end
Mounting Position: Any
Weight: 0.0023 oz., 0.065 g
Handling precautin:None
Electrical Characteristic
1.Maximum & Thermal Characteristics Ratings at 25°C ambient temperature unless otherwise specified.
Parameter Symbol
symbol
Device marking code
FM
401
M01
FM
402
M02
FM
403
M03
FM
404
M04
FM
405
M05
FM
406
M06
FM
407
M07
Unit
Maximum repetitive peak reverse voltage
VRRM
50
100
200
400
600
800
1000
Maximum RSM voltage
VRSM
35
70
140
280
420
560
700
V
Maximum DC blocking voltage
VDC
50
100
200
400
600
800
1000
V
Maximum average forward rectified current
land areas at Tc = 75°C(Note 1)
Peak forward surge current 8.3ms single half sinewave superimposed on rated load (JEDEC Method)
Typical thermal resistance (Note 1)
Operating junction and storage temperature range
V
IF(AV)
1.0
A
IFSM
30
A
RθJA
RθJC
TJ, TSTG
150
45
–50 to +150
°C/W
°C
Electrical Characteristics Ratings at 25°C ambient temperature unless otherwise specified.
Parameter Symbol
Maximum instantaneous forward voltage at 1.0A
Maximum DC reverse current TA = 25°C
at rated DC blocking voltage TA = 125°C
Typical junction capacitance at 4.0V, 1MHz
NOTES:
1. 8.0mm2 (.013mm thick) land areas
symbol
VF
IR
CJ
FM
401
FM
402
FM
403
FM
404
1.1
5.0
50
15.0
FM
405
FM
406
FM
407
Unit
V
µA
PF
FM401 thru FM407
2.Ratings and Characteristic Curves ( TA = 25°C unless otherwise noted )
1.0
0.5
8.0mm2 (.013mm thick) land areas
0
100
25 50 75 100 125
Case Temperature, °C
10
0.1
Transient thermal impedance(°C/W)
0.01
0.6
100
20
10
0
1
Fig 3. – Typical Instantaneous Forward
Characteristics
1.0
0.8
1.0
1.2
1.4
1.6
Instantaneous Forward Voltage (V)
100
Fig 4. – Typical Reverse Characteristics
Tj=125℃
10
1.0
Tj=25℃
0.1
0.01
0
20
40
60
80
100
Percent of Rated Peak Reverse Voltage (%)
Fig 6. – Typical Junction Capacitance
10
1.0
0.1
0.1
1.0
10
t,Pulse duration,sec
10
Number of Cycles at 60Hz
100
Fig 5. –typical transient thermal
impedance
0.01
TJ = TJ max
8.3ms Single Half Sine-wave
(JEDEC Method)
30
150 175
TJ = 25°C
Pulse width = 300µs
1% Duty Cycle
Fig. 2 – Maximum Non-repetitive Peak
Forward Surge Current
40
Instantaneous Reverse Current (µA)
Instantaneous Forward Current (A)
0
50
Average Forward Rectified Current (A)
60 Hz
Resistive or
Inductive Load
Junction Capacitance (pF)
Average Forward Rectified Current (A)
Fig. 1 – Forward Current Derating Curve
100
20
TJ = 25°C
f = 1.0 MHz
Vsig = 50mVp-p
10
1.0
0.1
1
10
Reverse Voltage (V)
100
FM401 thru FM407
3. dimension:
T
Dimensions
inches
A
B
C
D
E
F
T
Min.
0.086
0.051
0.185
0.067
0.035
0.035
0.055
mm
Max.
0.11
0.067
0.209
0.1
0.059
0.059
0.071
Min.
2.2
1.3
4.7
1.7
0.9
0.9
1.4
Max.
2.8
1.7
5.3
2.55
1.5
1.5
1.8
Note:
DO-214AC
molded plastic case
The marking band indicates the
cathode
FM401 thru FM407
4. Update Record
版次
更新记录
更新作者
更新日期
1
第一版
周杰
2010-4-13
2
增加包装规范
周杰
2011-9-13
3
修改热阻和降额温度
谭志伟
2016-9-1
