LBSS260DW1T1G

LBSS260DW1T1G S-LBSS260DW1T1G N-Channel 60-V Power Mosfet 1. FEATURES ● High speed switch ● ESD protected ● We declare that the material of product compliance with RoHS requirements and Halogen Free. ● SC88(SOT-363) S- prefix for automotive and other applications requiring unique site and control change requirements; AEC-Q101 qualified and PPAP capable. 2. APPLICATION Portable appliances ● Load switch appliances ● 3. DEVICE MARKING AND ORDERING INFORMATION Device Marking Shipping LBSS260DW1T1G J3 3000/Tape&Reel LBSS260DW1T3G J3 10000/Tape&Reel 4. MAXIMUM RATINGS(Ta = 25ºC) Parameter Drain–Source Voltage Gate–to–Source Voltage – Continuous Symbol Limits Unit VDSS 60 Vdc VGS ±20 Drain Current Vdc mAdc – Continuous TA = 25°C – Pulsed (tp≤10μs) ID 200 IDM 800 Symbol Limits Unit PD 380 mW 3.05 mW/ºC RΘJA 328 ºC/W TJ,Tstg −55∼+150 ºC 260 ºC 5. THERMAL CHARACTERISTICS Parameter Total Device Dissipation, FR−4 Board (Note 1) @ TA = 25ºC Derate above 25ºC Thermal Resistance, Junction–to–Ambient(Note 1) Junction and Storage temperature Maximum Lead Temperature for Soldering TL Purposes, for 10 seconds 1. FR–4 = 1.0×0.75×0.062 in. Leshan Radio Company, LTD. Rev.O Feb. 2017 1/5 LBSS260DW1T1G, S-LBSS260DW1T1G Power MOSFET 6. ELECTRICAL CHARACTERISTICS (Ta= 25ºC) OFF CHARACTERISTICS Characteristic Symbol Drain–Source Breakdown Voltage VBRDSS (VGS = 0, ID = 250μAdc) Zero Gate Voltage Drain Current IDSS (VGS = 0, VDS = 55 Vdc) Gate–Body Leakage Current, Forward IGSSF (VGS=20V, VDS=0V) Gate–Body Leakage Current, Reverse IGSSR (VGS= -20V, VDS=0V) Min. Typ. Max. 60 - - Unit Vdc μAdc - - 0.1 μAdc - - 5 μAdc - - -5 ON CHARACTERISTICS (Note 2) Gate Threshold Voltage VGS(th) (VDS=VGS,IDS=250μA) Static Drain–Source On–State Resistance Vdc 0.5 - 1.0 RDS(on) Ohms (VGS=10V,IDS=0.5A) - - (VGS=4.5V,ID=0.1A) - - 2 (VGS=2.5V, IDS=0.05A) - - 2.5 (VGS=1.8V, IDS=0.01A) - - 3 Diode Forward Voltage VSD (ISD = 0.5 A, VGS = 0 V ) 1.44 Vdc 0.5 - 1.35 DYNAMIC CHARACTERISTICS Input Capacitance Ciss (VDS = 25 Vdc, VGS = 0, f = 1.0 MHz) Output Capacitance Coss (VDS = 25 Vdc, VGS = 0, f = 1.0 MHz) Reverse Transfer Capacitance Crss (VDS = 25 Vdc, VGS = 0, f = 1.0 MHz) pF - 22.8 - - 3.5 - pF pF - 2.9 - SWITCHING CHARACTERISTICS Turn-On Delay Time Turn-Off Delay Time ns (VDD = 30 Vdc , VGEN = 10 V,RG =25Ω ,RL =60 Ω,ID =500 mAdc) td(on) - 3.8 - td(off) - 19 - 2.Pulse Test: Pulse Width ≤300 μs, Duty Cycle ≤2.0%. Leshan Radio Company, LTD. Rev.O Feb. 2017 2/5 LBSS260DW1T1G, S-LBSS260DW1T1G Power MOSFET 7.ELECTRICAL CHARACTERISTICS CURVES 3.0 0.8 Ta=25℃ VDS=5V 0.7 2.5 2.5V RDSON(Ω） ID,Drain current(A) 0.6 0.5 0.4 0.3 25℃ 2.0 4.5V 1.5 0.2 150℃ 1.0 -55℃ 0.1 6.5V ,8.5V ,10V 0 0.5 0.5 1 1.5 2 2.5 3 0.5 0.6 0.7 0.8 0.9 1 ID,Drain current(A) VGS,Gate to Source(V) RDSON vs. ID ID vs. VGS 12.00 1 4V ID=0.5A Ta=25℃ 0.9 10.00 3V 0.8 5V -55℃ 8.00 2.5V RDSON(Ω） RDSON(Ω） 0.7 0.6 0.5 0.4 2V 6.00 4.00 0.3 155℃ 0.2 2.00 25℃ 1.5V 0.1 0.00 0 0 1 2 3 4 VDS,Drain to Source Voltage(V) 5 2 RDSON vs. VDS Leshan Radio Company, LTD. 4 6 8 VGS,Gate to Source Voltage(V) 10 RDSON vs. VGS Rev.O Feb. 2017 3/5 LBSS260DW1T1G, S-LBSS260DW1T1G Power MOSFET 7.ELECTRICAL CHARACTERISTICS CURVES(Con.) 1 2.0 ID=250uA 1.5 150℃ 0.1 VGSTH(V) IS(A) 25℃ -55℃ 1.0 0.5 0.0 0.01 0.4 0.5 0.6 0.7 0.8 VSD(V) 0.9 1 1.1 -50 0 25 50 75 Tj(℃） 100 125 150 VGSTH vs. TJ IS vs. VSD Leshan Radio Company, LTD. -25 Rev.O Feb. 2017 4/5 LBSS260DW1T1G, S-LBSS260DW1T1G Power MOSFET 8.OUTLINE AND DIMENSIONS Notes: 1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982. 2. CONTROLLING DIMENSION: MILLIMETERS. 3. MAXIMUM LEAD THICKNESS INCLUDES LEAD FINISH. MINIMUM LEAD THICKNESS IS THE MINIMUM THICKNESS OF BASE MATERIAL. 4. DIMENSIONS D AND E DO NOT INCLUDE MOLD FLASH, PROTRUSIONS OR GATE BURRS. MILLIMETERS INCHES DIM A MIN NOM MAX MIN NOM MAX --- --- 1.10 --- --- 0.043 A1 0.00 --- 0.10 0 --- 0.004 A2 0.70 0.90 1.00 0.027 0.035 0.039 b 0.15 0.20 0.25 0.006 0.008 C 0.08 0.15 0.22 0.003 0.006 0.009 D 1.80 2.00 2.20 0.07 E 2.00 2.10 2.20 0.078 0.082 0.086 E1 1.15 1.25 1.35 0.045 0.049 0.053 0.46 0.010 0.014 0.018 e L 0.65 BSC 0.26 0.36 0.01 0.078 0.086 0.026 BSC L2 0.15 BSC 0.006 BSC aaa 0.15 0.01 bbb 0.30 0.01 ccc 0.10 0.00 ddd 0.10 0.00 9.SOLDERING FOOTPRINT Leshan Radio Company, LTD. Rev.O Feb. 2017 5/5
