LESD8D8.0T5G

LESHAN RADIO COMPANY, LTD. LESD8D8.0T5G Transient Voltage Suppressors Discription The LESD8D8.0T5G is designed to protect voltage sensitive components from ESD. Excellent clamping capability, low leakage, and fast response time provide best in class protection on designs that are exposed to ESD. Because of its small size, it is suited for use in cellular phones, digital cameras and many other portable applications where board space is at a premium. LESD8D8.0T5G 1 2 Applications l Cellular phones audio l l l Digital cameras SOD882 Portable applications Mobile telephone CATHODE Features l Small Body Outline Dimensions: Ordering information 0.039 ″ x 0.024 ″ (1.0 mm x 0.60 mm) l l l l l l ANODE Device Low Body Height: 0.020 ″ (0.50 mm) Low Leakage Marking LESD8D8.0T5G 7A Shipping 10000/Tape&Reel Response Time is Typically < 1 ns ESD Rating of Class 3 per Human Body Model IEC61000−4−2 Level 4 ESD Protection These are Pb−Free Devices MAXIMUM RATINGS Rating IEC 61000-4-2 (ESD) Symbol discharge Air Contact discharge Value Unit ±30 ±330 kV kV Peak Pulse Current (8/20µs) Ppk 400 W Total Power Dissipation on FR-5 Board (Note 1) @ TA=25℃ PD 150 mW Junction and Storage Temperature Range TJ,TSTG -55 to 150 ℃ Lead Solder Temperature – Maximum (10 Second Duration) TL 260 ℃ Stresses exceeding Maximum Ratings may damage the device. Maximum Rating are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. 1. FR-5 = 1.0*0.75*0.62 in. Oct. 2020 9 Rev.D 1/4 LESHAN RADIO COMPANY, LTD. LESD8D8.0T5G ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted) Symbol I Parameter IPP Maximum Reverse Peak Pulse Current VC Clamping Voltage @ IPP VRWM IR VBR Working Peak Reverse Voltage VC VBR VRWM Maximum Reverse Leakage Current @ VRWM Breakdown Voltage @ IT IT Test Current IF Forward Current VF Forward Voltage @ IF Ppk Peak Power Dissipation C IF V IR VF IT IPP Uni−Directional TVS Capacitance @ VR = 0 and f = 1.0 MHz ELECTRICAL CHARACTERISTICS Parameter Reverse Working Voltage Symbol Min Typ VRWM Max Unit 8 V 10.5 V Breakdown Voltage VBR Peak Pulse Current (8/20µs) IPP 25 A Reverse Leakage Current IR 2 μA Clamping Voltage VC 8.5 9.5 10.5 16 18 Test Condition IR = 1mA VRM= 8 8V V IPP = 2A (8 x 20µs pulse) V IPP = 4 25A(8 x 20µs pulse) ESD Clamping Voltage VC 13 V IPP = 16A(tp = 100ns (TLP)) Junction Capacitance CJ 150 pF VR = 0V, f = 1MHz Oct. 2020 9 Rev.D 2/4 LESHAN RADIO COMPANY, LTD. LESD8D8.0T5G Typical Performance Characteristics (T A=25°C unless otherwise Specified) 100 90 % of Rated Power 80 70 60 50 Peak Pluse Power 8/20µs 40 30 20 10 0 0 25 50 75 100 125 150 Lead Temperature- TL(℃) Fig1. Pulse Waveform Fig2.Power Derating Curve 20 20 15 tp=100ns 16 Clamping Voltage_Vc (V) TLP Current (A) 10 5 0 -5 -10 -15 -20 -15 12 8 4 0 -12 Oct. 2020 9 -3 -6 0 TLP Voltage (V) Fig3.TLP Measurement -9 3 6 0 5 10 15 20 25 Peak Pulse Current_Ipp (A) 30 Fig4.Clamping Voltage vs. Peak Pulse Current 2 Rev.D 3/4 LESHAN RADIO COMPANY, LTD. LESD8D8.0T5G OUTLINE AND DIMENSIONS SOLDERING FOOTPRINT Oct. 2020 9 Rev.D 4/4 LESHAN RADIO COMPANY, LTD. DISCLAIMER ● Before you use our Products, you are requested to carefully read this document and fully understand its contents. LRC shall not be in any way responsible or liable for failure, malfunction or accident arising from the use of any LRC’s Products against warning, caution or note contained in this document. ● All information contained in this document is current as of the issuing date and subject to change without any prior notice. Before purchasing or using LRC's Products,please confirm the latest information with a LRC sales representative.
