2023 Series Air Dielectric Directional Couplers Low Loss, Octave Bandwidth Features • • • • Air Dielectric for Low Loss Frequency Range: 1.0 to 18 GHz Octave Bandwidths Meets MIL-E-5400 Environments Rev. V2 Outline Drawing Description These directional couplers feature compact packaging and four-port construction. This is combination permits flexibility in system designs. They are intended for test and measurement setups as well as for system use. Temperature range is –54o to +110oC. These units incorporate three miniature, low VSWR SMA jack connectors. Isolated port is terminated with 1/2 watt, 50 ohm load. Mechanical Specifications Case Style A Inch (mm) B Inch (mm) C Inch (mm) D Inch (mm) E Inch (mm) F Inch (mm) 0.38 (9.7) 0.38 (9.7) 0.38 (9.7) 0.38 (9.7) 0.38 (9.7) G Inch (mm) H Weight Inch (mm) oz 1.90 1.10 1.07 0.98 1.01 Weight g 54 31 31 28 30 1 2 3 4 5 2.55 (64.8) 2.39 (60.8) 1.97 (50.1) 1.16 (29.4) 0.50 (12.7) 1.69 (42.7) 1.52 (38.7) 1.11 (28.2) 1.16 (29.4) 0.50 (12.7) 1.41 (35.6) 1.24 (31.5) 0.82 (20.8) 1.16 (29.4) 0.50 (12.7) 1.19 (30.0) 1.02 (26.0) 0.60 (15.2) 1.16 (29.4) 0.50 (12.7) 1.08 (27.4) 0.92 (23.4) 0.50 (12.7) 1.28 (32.6) 0.63 (15.9) 0.91 (23.2) 0.093 (2.36) 0.91 (23.2) 0.093 (2.36) 0.91 (23.2) 0.093 (2.36) 0.91 (23.2) 0.093 (2.36) 0.97 (24.6) 0.093 (2.36) 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. 2023 Series Air Dielectric Directional Couplers Low Loss, Octave Bandwidth Specifications Part Number Case Style Freq. Range (GHz) Coupling Freq. Insertion (Include. Sens. Loss Max Freq. (dB) (dB) Sens.(dB) Direct. Min. (dB) VSWR Max Prim Line Power Avg. (W) Power Pk. (kW) M/A-COM MIL-C15370/10* Commercial Equivalent Part No. 2023-4011-06 2023-4012-10 2023-4013-20 — — — — — — 2023-4016-10 2023-4017-20 2023-4085-06 — — Rev. V2 2023-6121-06 2023-6122-10 2023-6123-20 2023-6125-10 2023-6126-20 2023-6127-06 2023-6128-10 2023-6129-20 2023-6133-06 2023-6134-10 2023-6135-20 2023-6136-06 2023-6137-10 2023-6138-20 1 1 1 2 2 3 3 3 5 5 5 5 5 5 1.0-2.0 6 ± 1.0 10 ± 1.0 20 ± 1.0 10 ± 1.0 20 ± 1.0 6 ± 1.0 10 ± 1.0 20 ± 1.0 6 ± 1.0 10 ± 1.0 20 ± 1.0 6 ± 0.75 10 ± 0.75 20 ± 0.75 ±0.50 ±0.75 ±1.0 ±0.75 ±1.0 ±0.60 ±0.75 ±1.0 ±0.50 ±0.75 ±1.0 ±0.60 ±0.75 ±1.0 0.20 0.20 0.20 0.20 0.20 0.20 0.20 0.20 0.25 0.25 0.25 0.25 0.25 0.25 20 20 20 20 20 18 18 18 15 15 15 12 12 12 1.20 1.20 1.20 1.20 1.20 1.25 1.25 1.25 1.30 1.30 1.30 1.35 1.35 1.35 2 5 50 5 50 2 5 50 2 5 50 2 5 50 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2.0-4.0 2.6-5.2 8.0-12.4 12.4-18.0 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
