A33

A33 / SMA33 Cascadable Amplifier 10 to 2000 MHz Features • • • • AVAILABLE IN SURFACE MOUNT LOW NOISE FIGURE: 4.5 dB (TYP.) +3 dBm OUTPUT LEVEL (TYP.) WIDE POWER SUPPLY RANGE +8 TO +15 VOLTS Rev. V2 Product Image Description The A33 RF amplifier is a discrete thin film hybrid design, which incorporates the use of thin film manufacturing processes for accurate performance and high reliability. This single stage bipolar transistor feedback amplifier design displays impressive performance over a broadband frequency range. An active DC biasing network is used for temperature-stable performance, in addition to an RF Choke, used for power supply decoupling. Both TO-8 and Surface Mount packages are hermetically sealed, and MIL-STD-883 environmental screening is available. Ordering Information Part Number A33 MAAM-008718-0SMA33 MAAM-008718-00CA33 Package TO-8 Surface Mount SMA Connectorized ** ** The connectorized version is not RoHs compliant. Electrical Specifications: Z0 = 50Ω, VCC = +15 VDC Typical Parameter Frequency Small Signal Gain (min) Gain Flatness (max) Reverse Isolation Noise Figure (max) Power Output @ 1 dB comp. (min) IP3 IP2 Second Order Harmonic IP VSWR Input / Output (max) DC Current @ 15 Volts (max) mA Absolute Maximum Ratings Parameter Storage Temperature Case Temperature DC Voltage Continuous Input Power Short Term Input power (1 minute max.) Peak Power (3 µsec max.) “S” Series Burn-In Temperature (case) Guaranteed 0º to 50ºC 10-2000 8.5 ±0.8 Units 25ºC MHz dB dB dB dB dBm dBm dBm dBm 1-2050 9.5 ±0.5 15 4.5 3.0 +15 +22 Thermal Resistance θjc +28 Transistor Power Dissipation Pd 1.7:1 / 1.7:1 14 2.0:1 / 2.0:1 16 2.2:1 / 2.2:1 17 Junction Temperature Rise Above Case Tjc 5.5 2.5 6.0 2.0 Absolute Maximum -62ºC to +125ºC +125ºC +20 V +13 dBm 50 mW 1.5 W +125ºC -54º to +85ºC* 10-2000 8.0 ±1.0 Thermal Data: VCC = +15 VDC Parameter Rating 45ºC/W 0.165 W +7ºC * Over temperature performance limits for part number CA33, guaranteed from 0oC to +50oC only. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. A33 / SMA33 Cascadable Amplifier 10 to 2000 MHz Typical Performance Curves at +25°C Outline Drawing: TO-8 * Rev. V2 WEIGHT: 1 gram (0.04 oz.) max Outline Drawing: Surface Mount * WEIGHT: 1 gram (0.04 oz.) max Outline Drawing: SMA Connectorized * WEIGHT: 19 grams (0.67 oz.) max ∗ 2 Dimensions are inches (millimeters) ±0.015 (0.38) unless otherwise specified. ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
