A72 / SMA72 Cascadable Amplifier 5 to 500 MHz Features • LOW POWER DRAIN 31 mA (TYP.) • HIGH OUTPUT LEVEL: +12.5 dBm (TYP.) • HIGH IP3: +28 dBm (TYP.) AT Vcc = +8 Vdc Rev. V3 Product Image Description The A72 RF amplifier is a discrete thin film hybrid design, which incorporates the use of thin film manufacturing processes for accurate performance and high reliability. This single stage bipolar transistor feedback amplifier design displays impressive performance over a broadband frequency range. An active DC biasing network is used for temperature-stable performance, in addition to an RF Choke, used for power supply decoupling. Both TO-8 and Surface Mount packages are hermetically sealed, and MIL-STD-883 environmental screening is available. Ordering Information Part Number A72 SMA72 CA72 ** Package TO-8 Surface Mount SMA Connectorized ** The connectorized version is not RoHs compliant. Electrical Specifications: Z0 = 50Ω, VCC = +5 VDC Typical Parameter Frequency Small Signal Gain (min) Gain Flatness (max) Reverse Isolation Noise Figure (max) Power Output @ 1 dB comp. (min) IP3 IP2 Second Order Harmonic IP VSWR Input / Output (max) DC Current @ 5 Volts (max) mA Absolute Maximum Ratings Parameter Storage Temperature Case Temperature DC Voltage Continuous Input Power Short Term Input power (1 minute max.) Peak Power (3 µsec max.) “S” Series Burn-In Temperature (case) Guaranteed 0º to 50ºC 5-500 14.0 ±0.7 Units 25ºC MHz dB dB dB dB dBm dBm dBm dBm 2-700 15.0 ±0.2 20 3.3 12.5 +26 +36 +42 1.3:1 / 1.3:1 31 1.7:1 / 1.7:1 34 1.8:1 / 1.8:1 36 4.0 11.5 4.5 11.0 Absolute Maximum -62ºC to +125ºC 125ºC +9 V +13 dBm 50 mW 0.5 W 125ºC -54º to +85ºC* 5-500 13.5 ±1.0 Thermal Data: VCC = +5 VDC Parameter Thermal Resistance θjc Transistor Power Dissipation Pd Junction Temperature Rise Above Case Tjc Rating 140ºC/W 0.126 W 18ºC * Over temperature performance limits for part number CA72, guaranteed from 0oC to +50oC only. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. A72 / SMA72 Cascadable Amplifier 5 to 500 MHz Typical Performance Curves at +25°C Outline Drawing: TO-8 * Rev. V3 WEIGHT: 1 gram (0.04 oz.) max Outline Drawing: Surface Mount * WEIGHT: 1 gram (0.04 oz.) max Outline Drawing: SMA Connectorized * WEIGHT: 19 grams (0.67 oz.) max ∗ 2 Dimensions are inches (millimeters) ±0.015 (0.38) unless otherwise specified. ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
