AT-280

AT-280 Digital Attenuator, 15.5 dB, 5-Bit DC - 2.0 GHz Features • • • • • • 0.5 dB Attenuation Steps to 15.5 dB Ultra Low DC Power Consumption Low Intermodulation Product: +45 dBm IP3 SOIC-16 Plastic Package Tape and Reel Packaging Available Temperature Stability: +/-0.15 dB from -40°C to +85°C Rev. V5 Functional Schematic Description M/A-COM’s AT-280 is a 5-bit, 0.5-dB step GaAs MMIC digital attenuator in a low cost SOIC 16-lead surface mount plastic package. The AT-280 is ideally suited for use where high accuracy, fast switching, very low power consumption and low intermodulation products are required at a low cost. Typical applications include radio and cellular equipment, wireless LANS, GPS equipment and other gain/level control circuits. The AT-280 is fabricated with a monolithic GaAs MMIC using a mature 1-micron process. The process features full chip passivation for increased performance and reliability. Pin Configuration Pin No. 1 2 3 Function VC1 VC1 VC2 VC2 VC3 VC3 VC4 VC5 Pin No. 9 10 11 12 13 14 15 16 Function RF2 Ground Ground Ground Ground Ground Ground RF1 Ordering Information 1 Part Number AT-280 AT-280TR AT-280SMB 4 5 Package SOIC 16–Lead Forward Tape and Reel Sample Test Board (Includes 5 Samples) 6 7 8 Absolute Maximum Ratings 2 Parameter Input Power: 0.05 GHz 0.5 - 2.0 GHz Control Voltage Operating Temperature Storage Temperature 1. Reference Application Note M513 for reel size information. Absolute Maximum +27 dBm +34 dBm -8.5 V < VC < +5 V -40°C to +85°C -65°C to +150°C 2. Exceeding any one or combination of these limits may cause permanent damage to this device. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 / Fax: 978.366.2266 is considering for development. Performance is based on target specifications, simulated results, • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 and/or prototype measurements. Commitment to develop is not guaranteed. • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Visit www.macomtech.com for additional data sheets and product information. Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. AT-280 Digital Attenuator, 15.5 dB, 5-Bit DC - 2.0 GHz Electrical Specifications: TA = 25°C, Z0 = 50 Ω Parameter Reference Insertion Loss Rev. V5 Test Conditions DC—0.1 GHz DC—0.5 GHz DC—1.0 GHz DC—2.0 GHz DC—1.0 GHz DC—2.0 GHz (Any state) 10% to 90% RF, 90% to 10% RF 50% Control to 90% RF, 50% Control to 10% RF In Band Input Power, 0.05 GHz Input Power, 0.5 - 2.0 GHz 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (for two-tone input power up to +5 dBm) 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (for two-tone input power up to +5 dBm) Units dB dB dB dB Min — — — — Typ 1.1 1.3 1.5 1.8 Max 1.3 1.5 1.8 2.0 Attenuation Accuracy 3 VSWR Trise, Tfall Ton, Toff Transients 1 dB Compression ± (0.20 dB +3% of Attenuation Setting in dB) dB ± (0.30 dB +3% of Attenuation Setting in dB) dB Ratio nS nS mV dBm dBm dBm dBm 1.5:1 — — — — — — — 1.8:1 12 18 30 22 27 53 68 — — — — — — — — IP 2 IP 3 dBm dBm — — 40 45 — — 3. Attenuation acccuracy specifications apply with negative bias control and low inductance grounding. SOIC-16 Truth Table 4,5 Control Inputs VC 5 1 0 1 1 1 1 0 VC 4 1 1 0 1 1 1 0 VC 3 1 1 1 0 1 1 0 VC 3 0 0 0 1 0 0 1 VC 2 1 1 1 1 0 1 0 VC 2 0 0 0 0 1 0 1 VC 1 1 1 1 1 1 0 0 VC 1 0 0 0 0 0 1 1 Atten. (dB) Reference 0.5 dB 1 dB 2 dB 4 dB 8 dB 15.5 dB 4. 0 = Vin Low = 0 V = 0 to –0.2 V @ 20 µA maximum 5. 1 = Vin High = -5 V at 20 µA to -8 V at 20 µA maximum 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 / Fax: 978.366.2266 is considering for development. Performance is based on target specifications, simulated results, • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 and/or prototype measurements. Commitment to develop is not guaranteed. • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Visit www.macomtech.com for additional data sheets and product information. Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. AT-280 Digital Attenuator, 15.5 dB, 5-Bit DC - 2.0 GHz Typical Performance Curves Insertion Loss 3.0 Rev. V5 Attenuation Accuracy 0.3 0.5 dB Atten 1 dB Atten 2 dB Atten 4 dB Atten 8 dB Atten 15.5 dB Atten 2.5 +25°C -40°C +85°C 0.2 2.0 0.1 1.5 0.0 1.0 -0.1 0.5 -0.2 0.0 0.0 0.5 1.0 1.5 2.0 -0.3 0.0 0.5 1.0 1.5 2.0 Frequency (GHz) Frequency (GHz) VSWR 1.5 IL 1 dB 2 dB 4 dB 8 dB 16 dB 1.4 1.3 1.2 1.1 1.0 0.0 0.5 1.0 1.5 2.0 Frequency (GHz) 3 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 / Fax: 978.366.2266 is considering for development. Performance is based on target specifications, simulated results, • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 and/or prototype measurements. Commitment to develop is not guaranteed. • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Visit www.macomtech.com for additional data sheets and product information. Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
