CG1

G1 / SMG1 Voltage-Controlled Attenuator Module 5 to 2000 MHz Features • • • AVAILABLE IN SURFACE MOUNT LOW VSWR: < 1.8:1 (TYP.) LOW INSERTION LOSS: 2.0 dB TO 1000 MHz (TYP.) • LOW DISTORTION: -25 dBc (TYP.) AT Vcontrol = +15 V Description The G1 attenuator is a discrete hybrid design, which uses thin film manufacturing processes for accurate performance and high reliability. This design uses three pin diodes to provide a non linear attenuation response across a broadband frequency range. Both TO-8 and Surface Mount packages are hermetically sealed, and MIL-STD-883 environmental screening is available. Rev. V4 Product Image Ordering Information Part Number G1 SMG1 CG1 ** Package TO-8 Surface Mount SMA Connectorized ** The connectorized version is not RoHs compliant. Electrical Specifications: Z0 = 50Ω, VCC = +15 VDC Typical Parameter Units 25ºC 5-2200 36 30 23 2.0 2.5
