FR12

FR12 Series V8 Single Junction Drop-In Isolator 800MHz, 900MHz, 1800MHz, 1900MHz, 2100MHz Features • • • • 20dB Isolation 0.35dB Insertion Loss Low cost package Custom products available with alternative configurations such as couplers, attenuators, high power termination and reverse circulation. Outline Drawing Description M/A COM’s drop-in circulators and isolators, designed for Wireless base station and power amplifier applications, feature high reliability performance at a low cost. These designs feature a low cost package ideally suited for high volume manufacturing. M/A Com is one of the largest suppliers of isolator and circulators in the world. Electrical Specifications: Z0 = 50Ω Parameter Isolation Insertion Loss VSWR, all ports Circulation Absolute Maximum Ratings 1 Parameter Forward Power Reflected Power Operating Temperature Storage Temperature -30°C to +85°C 20dB minimum 0.35dB maximum 1.22:1 Clockwise Absolute Maximum 250 Watts 20 Watts -30°C to +85°C -45°C to +100°C 1. Operation of this device above any one of these parameters Ordering Information Part Number FR12-0001 FR12-0002 FR12-0003 FR12-0004 FR12-0009 Frequency Range (MHz) 869—894 925—960 1805—1880 1930—1990 2110—2170 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
