HH-105

厂商：
MA-COM
封装：
描述：
HH-105 - Hybrid Junction, 20 - 300 MHz - M/A-COM Technology Solutions, Inc.

数据手册：

下载HH-105.pdf

立即购买

详情介绍
数据手册
价格&库存

HH-105 数据手册

HH-105 Hybrid Junction, 20 - 300 MHz Features • 0o - 180o Hybrid in TO-5 Package • High Isolation • MIL-STD-883 Screening Available Rev. V3 TO-5-2 Description 3 dB Hybrids are ideal for dividing a signal into two signals of equal amplitude and a constant 90° or 180° phase differential and for Quadrature combining or performing summation/differential combining. Pin Configuration Pin No. 1 2 Function A B Pin No. 3 7 Function D C Electrical Specifications1: TA = -55°C to +85°C Parameter Insertion Loss Isolation Amplitude Balance2 VSWR Phase Balance Impedance Input Power 2 Test Conditions Less Coupling — — — — — — Frequency 20 - 300 MHz 20 - 300 MHz 20 - 300 MHz 20 - 300 MHz 20 - 300 MHz 20 - 300 MHz 20 - 300 MHz Units dB dB dB Ratio ° Ohms Watts Min — 28 — — — — — Typ — — — — — 50 — Max 1.0 — 0.25 1.3:1 2 — 0.5 1. All specifications apply with 50 ohm source and load impedance. This product contains elements protected by United States Patent umber 3,508,171 2. Differences measure between C & D feeding A or B. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. HH-105 Hybrid Junction, 20 - 300 MHz Functional Diagram Ordering Information Part Number HH-105 PIN Package TO-5-2 Rev. V3 Typical Performance Curves 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.

下载 PDF

HH-105

1. 物料型号： - 型号为HH-105 PIN，封装为TO-5-2。

2. 器件简介： - 3 dB Hybrids适用于将信号分成两个幅度相等且具有恒定90°或180°相位差的信号，用于正交组合或执行求和/差分组合。

3. 引脚分配： - 引脚1：A - 引脚2：B - 引脚3：D - 引脚7：C

4. 参数特性： - 插入损耗：20 - 300 MHz频率下，最小值为1.0 dB。 - 隔离度：20 - 300 MHz频率下，典型值为28 dB。 - 幅度平衡：20 - 300 MHz频率下，最大值为0.25 dB。 - 电压驻波比（VSWR）：20 - 300 MHz频率下，最大值为1.3:1。 - 相位平衡：20 - 300 MHz频率下，最大值为2度。 - 阻抗：20 - 300 MHz频率下，值为50欧姆。 - 输入功率：20 - 300 MHz频率下，最大值为0.5瓦特。

5. 功能详解： - 该器件为混合接头，工作频率范围为20 - 300 MHz，具有高隔离度，并且符合MIL-STD-883标准。

6. 应用信息： - 适用于需要信号分配和组合的应用，如通信系统。

7. 封装信息： - 封装类型为TO-5-2。
