M1H

M1H Double-Balanced Mixer Rev. V2 Features • • • • LO and RF: 1.8 to 6.2 GHz IF: DC to 2 GHZ LO Drive +7 dBm (nominal) High Isolation 35 dB (Typ.) Guaranteed Specifications1 Characteristics Min Typ. Max. Test Conditions SSB Conversion Loss And SSB Noise Figure 7.0 dB 8.5 dB 9.0 dB 8.5 dB 9.5 dB 10.0 dB fL & fR 1.8 to 4.2 GHz fI 0.01 to 1 GHz fL & fR 1.8 to 4.2 GHz fI 0.01 to 2 GHz fL & fR 1.8 to 6.2 GHz fI 0.01 to 2 GHz Isolation fL at R fL at I fL at R fL at I Conversion Compression 25 dB 15 dB 18 dB 15 dB 40 dB 25 dB 25 dB 20 dB 1.0 dB fL 1.8 to 4.2 GHz fL 4.2 to 6.2 GHz fR = 0 dBm fL at +7 dB, Notes: 1. Measure in a 50-Ohm system with nominal LO drive and downconverter application only, unless otherwise specified. The I-Port frequency range extends to DC for phase detection, pulse modulation, or attenuator applications, I-Port VSWR degrades from a 50-Ohm system at low IF frequencies. Absolute Maximum Ratings Storage Temperature Operating Temperature Peak RF Input Power Peak Input Current at 25 C Weight 31 gram (1.1 oz) max. o -65oC to +100oC -54oC to +100oC +17 dBm 50 mA DC 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M1H Double-Balanced Mixer Rev. V2 Typical Performance Curves at 25oC 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M1H Double-Balanced Mixer Rev. V2 Outline Drawing: M1H 3 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
