M2A

M2A / M2AC Double-Balanced Mixer Rev. V3 Features • • • • • LO 10 to 1500 MHz RF 10 to 1500 MHz IF DC to 800 MHz LO Drive +7 dBm (nominal) High Isolation 35 dB (typ) Product Image Description The M2A is a double balanced mixer, designed for use in military, commercial, and test equipment applications. The design utilizes Schottky ring quad diodes and broadband ferrite baluns to attain excellent performance. This mixer can also be used as a phase detector and/or bi-phase modulator since the IF port is DC coupled to the diodes. Environmental screening is available to MILSTD-883, MIL-STD-202, or MIL-DTL-28837, consult factory. Ordering Information Part Number M2A M2AC Package TO-8 SMA Connectorized Electrical Specifications: Z0 = 50Ω Lo = +7 dBm (Downconverter application only) Typical Parameter Test Conditions fR = 0.02 to 0.6 GHz, fL = 0.01 to 0.8 GHz, fI = 0.001 to 0.2 GHz fR = 0.01 to 1.5 GHz, fL = 0.01 to 1.5 GHz , fI = 0.001 to 0.2 GHz fI = 0.001 to 0.8 GHz Within 1 db of conversion loss fL = 0.01 to 0.5 GHz fL = 0.5 to 1.2 GHz fL = 1.2 to 1.5 GHz fL = 0.01 to 0.5 GHz fL = 0.5 to 1.2 GHz fL = 1.2 to 1.5 GHz fL = +7 dBm Guaranteed +25ºC -54º to +85ºC * 8.0 9.0 9.5 ____ Units SSB Conversion Loss (max) dB 7.0 7.5 8.0 ____ 45 40 35 40 30 25 0 7.5 8.5 9.0 ____ 35 28 25 30 20 18 SSB Noise Figure (max) dB Isolation, L to R (min) dB Isolation, L to I (min) dB 1 dB Conversion Comp. dBm Input IP3 dBm +12 * The M2AC specification limits apply at 0ºC to +50ºC. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M2A / M2AC Double-Balanced Mixer Rev. V3 Typical Performance Curves 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M2A / M2AC Double-Balanced Mixer Rev. V3 Absolute Maximum Ratings Parameter Operating Temperature Storage Temperature Peak Input Power Peak Input Current Outline Drawing: TO-8 * Absolute Maximum -54ºC to +100ºC -65ºC to +100ºC +23 dBm max @ +25ºC +17 dBm max @ +100ºC 50 mA DC Weight: 2 grams (0.07 oz.) max Outline Drawing: SMA Connectorized * Weight: 21 grams (0.74 oz.) max ∗ Dimensions are inches (millimeters) ±0.015 (0.38) unless otherwise specified. 3 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
