M2T / M2TC Triple-Balanced Mixer Rev. V3 Features • • • • • • LO 10 TO 2400 MHz RF 10 TO 2400 MHz IF 10 TO 1000 MHz LO DRIVE: +13 dBm (NOMINAL) HIGH INTERCEPT: +22 dBm (TYP.) HIGH ISOLATION: 40 dB (TYP.) Product Image Description The M2T is a triple balanced mixer, designed for use in military, commercial and test equipment applications. The design utilizes Schottky ring quad diodes and broadband soft dielectric baluns to attain excellent performance. The use of high temperature solder and welded assembly processes used internally makes it ideal for use in manual, semi-automated assembly. Environmental screening available to MIL-STD-883, MIL-STD-202 or MIL-DTL28837, consult factory. Ordering Information Part Number M2T M2TC Package TO-8 SMA Connectorized Electrical Specifications: Z0 = 50Ω Lo = +13 dBm (Downconverter application only) Typical Parameter Test Conditions Units +25ºC SSB Conversion Loss (max) & SSB Noise Figure (max) Guaranteed -54º to +85ºC * fR = 0.01 to 2.4 GHz, fL =0.01 to 2.4 GHz, fI =0.05 to 1 GHz fR = 0.01 to 2.4 GHz, fL =0.01 to 2.4 GHz, fI =0.01 to 1 GHz fR = 0.5 to 1.5 GHz, fL =0.5 to 1.5 GHz, fI =0.01 to 1 GHz dB dB dB 7.5 9.0 7.0 9.5 10.0 8.5 10.0 10.5 9.0 Isolation, L to R (min) fL = 0.01 to 1.2 GHz fL = 1.2 to 2.4 GHz dB dB 40 40 35 30 33 28 Isolation, L to I (min) fL = 0.01 to 1.2 GHz fL = 1.2 to 2.4 GHz dB dB 40 40 35 30 33 28 1 dB Conversion Comp. Input IP3 fL @ +13 dBm dBm +11 +22 * The M2TC specification limits apply at 0ºC to +50ºC. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M2T / M2TC Triple-Balanced Mixer Rev. V3 Typical Performance Curves 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M2T / M2TC Triple-Balanced Mixer Rev. V3 Absolute Maximum Ratings Parameter Operating Temperature Storage Temperature Peak Input Power Peak Input Current Outline Drawing: TO-8 * Absolute Maximum -54ºC to +100ºC -65ºC to +100ºC +25 dBm max @ +25ºC +4 dBm max @ +100ºC 75 mA DC Weight: 2 grams (0.07 oz.) max Outline Drawing: SMA Connectorized * Weight: 21 grams (0.74 oz.) max ∗ Dimensions are inches (millimeters) ±0.015 (0.38) unless otherwise specified. 3 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
