M5T Wideband Load Insensitive Mixer Rev. V2 Features • • • • • • LO 50 TO 5000 MHz RF 50 TO 5000 MHz IF 50 TO 3000 MHz LO DRIVE +10 dBm (NOMINAL) INSENSITIVE TO SYSTEM LOAD MISMATCH HIGH INTERCEPT: +18 dBm (TYP.) Product Image Description The M5T is a termination insensitive mixer, designed for use in military, commercial and test equipment applications. The design utilizes Schottky bridge quad diodes, broadband ferrite baluns and internal loads to provide excellent performance without degradation due to external VSWR mismatches. The use of high temperature solder and welded assembly processes used internally makes it ideal for use in semi-automated and automated assembly. Environmental screening available to MIL-STD-883, MIL-STD-202, or MIL-DTL-28837, consult factory. Ordering Information Part Number M5T Package Flatpack Electrical Specifications: Z0 = 50Ω Lo = +10 dBm (Downconverter application only) Typical Parameter Test Conditions Units +25ºC SSB Conversion Loss (max) & SSB Noise Figure (max) fR = 0.05 to 1.5 GHz, fL = 0.05 to 1.5 GHz, fI = 0.05 to 1.5 GHz fR = 1.5 to 3 GHz, fL = 1.5 to 3 GHz , fI = 0.05 to 3.0 GHz fR = 3.0 to 5.0 GHz, fL = 3.0 to 5.0 GHz, fI = 0.05 to 3.0 GHz Guaranteed -54º to +85ºC 9.2 9.7 12.0 23 20 30 20 dB dB dB dB dB dB dB dB dBm dBm 7.2 8.0 9.0 35 33 40 35 33 +7 +18 2.0:1 1.8:1 1.5:1 8.5 9.0 11.3 25 23 32 22 Isolation, L to R (min) Isolation, L to I (min) Isolation, R to I (min) 1 dB Conversion Comp. Input IP3 (min.) fL = 0.05 to 1.0 GHz fL = 1.0 to 5.0 GHz fL = 0.05 to 1.0 GHz fL = 1.0 to 5.0 GHz fR = 0.05 to 5.0 GHz fL= +10 dBm fL = 0.05 to 5.0 GHz, fR = 0.05 to 5.0 GHz, fI = 0.05 to 3.0 GHz R-Port fR = 0.05 to 5.0 GHz, L-Port fL = 0.05 to 5.0 GHz, I-Port fI =0.05 to 3.0 GHz VSWR 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M5T Wideband Load Insensitive Mixer Rev. V2 Absolute Maximum Ratings Parameter Operating Temperature Storage Temperature Peak Input Power Peak Input Current Outline Drawing: Flatpack * Absolute Maximum -54ºC to +100ºC -65ºC to +100ºC +20 dBm max @ +25ºC +17 dBm max @ +100ºC 50 mA DC Weight: 1 gram (0.04 oz.) max. ∗ Dimensions are inches (millimeters) ±0.015 (0.38) unless otherwise specified. 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
