M6V

M6V / SM6V Double-Balanced Mixer Rev. V2 Product Image Features • • • • • LO 0.4 TO 500 MHz RF 0.4 TO 500 MHz IF DC TO 500 MHz LO DRIVE +7 dBm (nominal) HIGH ISOLATION 50 dB (TYP.) Description The M6V is a double balanced mixer, designed for use in military, commercial, and test equipment applications. The design utilizes Schottky ring quad diodes and broadband ferrite baluns to attain excellent performance. This mixer can also be used as a phase detector and/or bi-phase modulator since the IF port is DC coupled to the diodes. Environmental screening is available to MIL-STD-883, MIL-STD-202, or MIL-DTL-28837, consult factory. Ordering Information Part Number M6V SM6V Package TO-5 Surface Mount Electrical Specifications: Z0 = 50Ω Lo = +7 dBm (Downconverter Application only) Typical Parameter Test Conditions Units 25ºC fR=0.001 to 0.2 GHz, fL=0.001 to 0.2 GHz, fI=0.001 to 0.2 GHz fR = 0.0004 to 0.5 GHz, fL = 0.0004 to 0.5 GHz, fI = 0.0004 to 0.5 GHz fL = 0.0004 to 0.06 GHz fL = 0.06 to 0.5 GHz Guaranteed 0º to 50ºC -54º to +85ºC SSB Conversion Loss & SSB Noise Figure (max) dB dB dB dB 6.0 7.0 55 40 6.5 7.5 45 30 7.0 8.0 43 28 Isolation, L to R (min) Isolation, L to I (min) fL = 0.0004 to 0.06 GHz fL = 0.06 to 0.5 GHz fL @ +7 dBm dB dB 45 30 30 20 28 18 1 dB Conversion Compression dBm +0 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M6V / SM6V Double-Balanced Mixer Rev. V2 Typical Performance Curves 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. M6V / SM6V Double-Balanced Mixer Rev. V2 Absolute Maximum Ratings Parameter Operating Temperature Storage Temperature Peak Input Power Peak Input Current Outline Drawing: TO-5 Absolute Maximum -54 C to +100ºC -65ºC to +100ºC 23 dBm max @ +25ºC 17 dBm max @ +100ºC 50 mA DC Outline Drawing: Surface Mount 3 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
