S10

S10 10 to 500 MHz Thin Film SPST Switch Rev. 03/02 • • • • LOW INSERTION LOSS: < 2.5 dB (TYP.) HIGH ON/OFF RATION: 60 dB (TYP.) LOW VSWR: 1.6:1 (TYP.) TTL COMPATABLE Specifications (Rev. Date: 03/02)* Characteristics Insertion Loss (max.) 10-100 MHz 100-300 MHz 300-500 MHz Isolation 10-100 MHz 100-300 MHz 300-500 MHz VSWR Input/Output (max.) in ON state 10-500 MHz Switching Speed (10-90%) DC Current (max.) at ±0.7 V *Measured in a 50-ohm system. Typical < 1. 7 dB < 2.0 dB < 2.5 dB > 67 dB > 62 dB > 48 dB 1.9:1 2 ns ±20 mA Guaranteed 0° to 50°C -54° to +85°C Schematic Diagram 2.3 dB 2.6 dB 4.0 dB 54 dB 50 dB 39 dB 2.4:1 5ns 2.7 dB 3.0 dB 4.5 dB 52 dB 48 dB 36 dB 2.6:1 6 ns Absolute Maximum Ratings Ambient Operating Temperature Storage Temperature Max. Case Temperature Max. DC Voltage Max. Continuous RF Input Power Max. Short Term RF Input Power Max. Peak Power (1 minute max.) “S” Series Burn-in Temperature (Case) -54° to +125°C -62°C to +125°C 125°C +6 Volts +10 dBm 100 mW 1W 125°C Switching Conditions ON State +20 mA ≈ +0.7 V Off State -20 mA ≈ -0.7 V Outline Drawings Package Figure Model TO-8 BD S10 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions is considering for development. Performance is based on target specifications, simulated results, and/or prototype measurements. Commitment to develop is not guaranteed. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. Commitment to produce in volume is not guaranteed. • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 • India Tel: +91.80.43537383 • China Tel: +86.21.2407.1588 Visit www.macomtech.com for additional data sheets and product information. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. S10 10 to 500 MHz Thin Film SPST Switch Typical Performance at 25°C Rev. 03/02 Typical Automatic Test Data 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions is considering for development. Performance is based on target specifications, simulated results, and/or prototype measurements. Commitment to develop is not guaranteed. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. Commitment to produce in volume is not guaranteed. • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 • India Tel: +91.80.43537383 • China Tel: +86.21.2407.1588 Visit www.macomtech.com for additional data sheets and product information. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
