TP-101

TP-101 RF Pulse Transformer, 500 KHz - 1.5 GHz Features • • • • 50 Ohms Unbalanced/50 Ohms Balanced Fast Rise Time: 0.18 nS Low Insertion Loss: 0.4 dB Typical MIL-STD-202 Screening Available Rev. V3 FP-1 Description The transformer coupled balun can provide a wide frequency range. DC isolation from primary coil to secondary coil is also a feature of this device. Schematic/Pin Configuration . Electrical Specifications: TA = -55°C to +85°C Parameter Impedance Insertion Loss VSWR Input Power Test Conditions Input - 50 Ohms Unbalanced Output - 50 Ohms Balanced — — Frequency — 10 - 50 MHz 1 MHz - 1 GHz 750 KHz - 1.5 GHz 750 KHz - 1 MHz 1 MHz - 5 MHz 5 MHz - 1.5 GHz 10 - 90% — — — Units — dB Ratio Ratio Watts Watts Watts nS nS Min — — — — — — — — — Typ — — — — — — — 0.18 300 Max — 0.5 1.4:1 1.6:1 1.0 1.5 3.0 — — Rise Time Droop (10%) 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. TP-101 RF Pulse Transformer, 500 KHz - 1.5 GHz Typical Performance Curves Rev. V3 Ordering Information Part Number TP-101 PIN Package FP-1 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
