TP-102

TP-102 RF Pulse Transformer, 1 - 500 MHz Features • • • • 50 Ohms Unbalanced/200 Ohms Unbalanced Fast Rise Time: 0.35 nS Low Insertion Loss: 0.75 dB Typical MIL-STD-202 Screening Available Rev. V3 FP-1 Description The transformer coupled balun can provide a wide frequency range. DC isolation from primary coil to secondary coil is also a feature of this device. Schematic/Pin Configuration . Electrical Specifications: TA = -55°C to +85°C Parameter Impedance Insertion Loss VSWR Test Conditions Input - 50 Ohms Unbalanced Output - 200 Ohms Unbalanced — — Frequency — 10 - 50 MHz 5 MHz - 250 MHz 2 MHz - 500 MHz 1 - 2 MHz 1 MHz - 5 MHz 5 GHz - 1 GHz 10 - 90% — — — Units — dB Ratio Ratio Ratio Watts Watts nS nS Min — — — — — — — — — Typ — — — — — — — 0.35 150 Max — 0.75 1.3:1 1.6:1 2.0:1 0.5 1.0 — — Input Power Rise Time Droop (10%) 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. TP-102 RF Pulse Transformer, 1 - 500 MHz Typical Performance Curves Rev. V3 Ordering Information Part Number TP-102 PIN Package FP-1 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
