TP-103

厂商：
MA-COM
封装：
描述：
TP-103 - RF Pulse Transformer, 500 KHz - 1 GHz - M/A-COM Technology Solutions, Inc.

数据手册：

下载TP-103.pdf

立即购买

详情介绍
数据手册
价格&库存

TP-103 数据手册

TP-103 RF Pulse Transformer, 500 KHz - 1 GHz Features • • • • 50 Ohms Unbalanced/200 Ohms Balanced Fast Rise Time: 0.18 nS Low Insertion Loss: 0.4 dB Typical MIL-STD-202 Screening Available Rev. V3 FP-1 Description The transformer coupled balun can provide a wide frequency range. DC isolation from primary coil to secondary coil is also a feature of this device. Schematic/Pin Configuration 6 50 Ohms Unbalanced 2 200 Ohms Balanced . 4 Pins 1, 3, 5 are grounded to case Electrical Specifications: TA = -55°C to +85°C Parameter Impedance Insertion Loss VSWR Input Power Test Conditions Input - 50 Ohms Unbalanced Output - 200 Ohms Balanced — — Frequency — 10 - 50 MHz 2 - 500 MHz 500 KHz - 1 GHz 500 KHz - 1 MHz 1 MHz - 5 MHz 5 MHz - 1 GHz 10 - 90% — — — Units — dB Ratio Ratio Watts Watts Watts nS nS Min — — — — — — — — — Typ — — — — — — — 0.18 160 Max — 0.6 1.4:1 2.0:1 1.0 1.5 3.0 — — Rise Time Droop (10%) 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. TP-103 RF Pulse Transformer, 500 KHz - 1 GHz Typical Performance Curves Insertion Loss 3.0 Rev. V3 VSWR 1.8 1.6 2.0 1.4 1.0 1.2 1 0.1 0 .0 0.1 0.5 2 10 50 200 1000 3000 0.5 2 10 50 200 1000 3000 F re que nc y ( M H z) F requency ( M H z) Ordering Information Part Number TP-103 PIN Package FP-1 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.

下载 PDF

TP-103

1. 物料型号： - 型号：TP-103 - 封装：FP-1

2. 器件简介： - TP-103是一个射频脉冲变压器，工作频率范围为500 KHz至1 GHz。该变压器耦合平衡不平衡信号，并提供从初级线圈到次级线圈的直流隔离。

3. 引脚分配： - 引脚1、3、5接地至外壳。

4. 参数特性： - 阻抗：输入为50欧姆不平衡/输出为200欧姆平衡。 - 插入损耗：在10-50 MHz频率下，典型值为0.4 dB，最大值为0.6 dB。 - 电压驻波比（VSWR）：在2-500 MHz频率下为1.4:1，在500 KHz至1 GHz频率下为2.0:1。 - 输入功率：在500 KHz至1 MHz、1 MHz至5 MHz、5 MHz至1 GHz频率下分别为1.0瓦、1.5瓦和3.0瓦。 - 上升时间：0.18纳秒。 - 下降时间（10%）：160纳秒。

5. 功能详解： - 该变压器可以在宽频率范围内工作，并提供初级线圈到次级线圈的直流隔离。

6. 应用信息： - 适用于需要宽频率范围和直流隔离的射频应用。

7. 封装信息： - 封装类型为FP-1。
