TU-50

THV-50 / TU-50 Two-Way Power Dividers, 2 - 200 MHz and 20 - 400 MHz Features • • • Isolation - 30 dB Min Loss - 0.5 dB Max Low VSWR - 1.3:1 Max Rev. V2 C-7 Guaranteed Specifications: From –55oC to +85oC Model Frequency Range THV-50 2-200 TU-50 20-400 MHz Insertion Loss (less coupling) 0.5 0.5 dB Max Isolation Amplitude Balance Phase Balance VSWR (All Ports) 30 0.2 1.0 1.3:1 Max 30 dB Min 0.2 dB Max 2.0 o Max 1.3:1 Max Operating Characteristics Parameter Impedance Maximum Power Rating Or Input Power Internal Load Dissipation Enviornmental MIL-STD-202 screening available. * All specifications apply with 50 ohm source and load impedance. 1 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice. Absolute Maximum 50 Ohms Nominal 2.0 Watt Max 0.5 Watt Max THV-50 / TU-50 Two-Way Power Dividers, 2 - 200 MHz and 20 - 400 MHz Typical Performance Curves Ordering Information Part Number THV-50 BNC THV-50 N THV-50 SMA THV-50 TNC TU-50 BNC TU-50 TNC TU-50 N TU-50 SMA Package Connectorized Connectorized Connectorized Connectorized Connectorized Connectorized Connectorized Connectorized Rev. V2 2 ADVANCED: Data Sheets contain information regarding a product M/A-COM Technology Solutions • North America Tel: 800.366.2266 • Europe Tel: +353.21.244.6400 is considering for development. Performance is based on target specifications, simulated results, • India Tel: +91.80.4155721 • China Tel: +86.21.2407.1588 and/or prototype measurements. Commitment to develop is not guaranteed. Visit www.macomtech.com for additional data sheets and product information. PRELIMINARY: Data Sheets contain information regarding a product M/A-COM Technology Solutions has under development. Performance is based on engineering tests. Specifications are typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available. M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make Commitment to produce in volume is not guaranteed. changes to the product(s) or information contained herein without notice.
