2401-2A-6002

2400 Series Delay On Operate Timer Fixed Timing, Relay Output Product Facts ■ ■ ■ ■ ■ ■ ■ DC input fixed delay on operate timer 2 Form C (DPDT), 2A output CMOS digital design Reverse polarity protection Hermetic package Built to MIL-R-83726 environmentals Customizing options include ■ Tighter timing tolerances ■ Header and mounting ■ Different input voltages Electrical Specifications Timing Range: 50 ms to 600 s. Tolerance: ±10% or 10 ms, whichever is greater. Recycle Time: 10 ms. Recovery Time: 20 ms. Input Data: Input Voltage: 18 to 31Vdc. Current Drain: 85mA @ 31Vdc, 25°C. Output Data: Output Form: 2 Form C (DPDT). Output Rating: 2A resistive at 30Vdc; 125mA resistive at 115Vac, 400 Hz. Transient Protection: 80Vdc for 50ms. CII 2400 series delay on operate timers combine solid state timing circuits with relay outputs in robust hermetically sealed enclosures. They are fixed timers. The 2 Form C (DPDT) output relay is rated 2A. Part Numbering System Typical Part Number 2401 –1 A – 1102 Model Number: 2401 = Fixed timer, -55°C to +85°C 2402 = Fixed timer, -55°C to +125°C Header Style (see Header Options drawings): 1 = Hook terminals 2 = Straight terminals, short 3 = Straight terminals, long Mounting (see outline dimension drawings): A = Plain case B = Bracket B C = Studs on side E = Bracket E Timing Code: Four-digit code for any value between 50ms and 600s. The timing code consists of four digits and gives the time in ms. The first three digits are the significant figures and the last digit is the number of zeros following the significant figures; thus 50 ms would be coded 0500, 1.1 s would read 1101, and 1 m (60 s) would be 6002. A typical part number would be 2401–1A–1102. This fixed timer operates at -55°C to +85°C, has hook terminals, style “A” mounting, and a time delay of 11s. 1.062 [26.97] Timing Diagram INPUT OUTPUT ON OFF ON OFF < DELAY > Outline Dimensions .75 [19.0] .297 [7.54] .120 DIA. [3.05] .375 [9.52] .488 [12.4] .25 [6.35] .210-.230 [5.33-5.84] .375 [9.52] .030 [.762] #4-40 STUDS .125 [3.18] .031 [.787] Environmental Specifications Temperature Range: -55°C to +85°C or -55°C to +125°C. Vibration: 20 G’s, 10 - 2,000 Hz. Shock: 50 G’s, 11 ± 1ms duration. Insulation Resistance: 1,000 megohms, min., at 500Vdc, all terminals to case. Dielectric Strength: 500Vrms, 60 Hz., at sea level, all terminals to case. Sealing: Hermetic, 1.3 in. (33.0mm) of mercury. Life: 100,000 operations, min. Weight: 1.2 oz (30g) max. 1.500 [38.1] MAX. 1.32 MAX. [33.53] .406 MAX. [10.31] .809 MAX. [20.55] .809 MAX. [20.55] .040-.047 [1.02-1.19] 1.078 [27.38] .096 DIA. [2.44] 1.32 MAX. [33.53] .312 [7.92] Mounting Option A Mounting Option B Mounting Option D Mounting Option E Wiring Diagram + Header Options .030 DIA. TYP. [4.77] .030 DIA. TYP. [4.77] – .188 TYP. [4.77] .188 TYP. [4.77] TERMINAL SPACING IS 0.2 [5.08] FOR ALL HEADERS 3.0 ± .031 [76.2 ± .787] Header Option 1 Header Option 2 Header Option 3 © 2005 by Tyco Electronics Corporation. All Rights Reserved. CII and TYCO are trademarks. Other products and company names mentioned herein may be trademarks of their respective owners. 1 Catalog 7-1773439-9 Revised 4-05 www.tycoelectronics.com Dimensions are in inches and millimeters unless otherwise specified. Values in brackets are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. USA: 1-800-522-6752 Canada: 1-905-470-4425 Mexico: 01-800-733-8926 C. America: 52-55-5-729-0425 South America: 55-11-3611-1514 Hong Kong: 852-2735-1628 Japan: 81-44-844-8013 UK: 44-141-810-8967
