AT-107-TB

RoHS Compliant Digital Attenuator 31.5 dB, 6-Bit, TTL Driver, DC-2.0 GHz Features • Attenuation: 0.5 dB steps to 31.5 dB • Temperature Stability: ± 0.18 dB from –55°C to +85°C Typical • Low DC Power Consumption • Hermetic Surface Mount Package • Integral TTL Driver • 50 Ohm Nominal Impedance • Lead-Free CR-13 Package • 260°C Reflow Compatible AT-107-PIN V7 Functional Schematic Description M/A-COM’s AT-107-PIN is a GaAs FET 6-bit digital attenuator with a 0.5 dB minimum step size and 31.5 dB total attenuation. This attenuator and integral TTL driver is in a hermetically sealed ceramic 24lead surface mount package. The AT-107-PIN is ideally suited for use where accuracy, fast switching, very low power consumption and low intermodulation products are required. Typical applications include dynamic range setting in precision receiver circuits and other gain/leveling control circuits. Environmental screening is available. Contact the factory for information. Pin Configuration Pin No. 1 2 3 4 5 Function GND GND GND C16 C8 Vee (-5V to -8V) Vcc (+5V) C4 C2 C1 C0.5 GND Pin No. 13 14 15 16 17 18 19 20 21 22 23 24 Function RF2 GND GND GND GND GND GND GND GND GND GND RF1 Ordering Information Part Number AT-107-PIN AT-107-TB 6 7 Package Bulk Packaging Sample Test Board 8 9 10 11 Note: Reference Application Note M513 for reel size information. Note: Die quantity varies. 12 The metal bottom of the case must be connected to RF and DC ground. * Restrictions on Hazardous Substances, European Union Directive 2002/95/EC. 1 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information. RoHS Compliant Digital Attenuator 31.5 dB, 6-Bit, TTL Driver, DC-2.0 GHz Electrical Specifications: TA = -55°C to +85°C 1 Parameter Reference Insertion Loss AT-107-PIN V7 Test Conditions — Frequency DC - 0.5 GHz DC - 1.0 GHz DC - 2.0 GHz DC - 1.0 GHz DC - 2.0 GHz DC - 1.0 GHz DC - 2.0 GHz Units dB dB dB Min — — — Typ — — — Max 3.2 3.6 4.0 Attenuation Accuracy 2 Any Single Bit Any Combination of Bits ± (0.15 +3% of atten. setting in dB) dB ± (0.2 +3% of atten. setting in dB) dB ± (0.2 +3% of atten. setting in dB) dB or ± 0.4 dB, whichever is greater ± (0.2 +3% of atten. setting in dB) dB or ± 0.4 dB, whichever is greater Ratio ns ns mV dBm dBm dBm dBm dBm dBm V V mA — — — — — — — — — — 4.5 -8.0 — — 9 45 40 +21 +29 +35 +48 +75 +79 5.0 — — 1.8:1 — — — — — — — — — 5.5 -5.0 6.0 VSWR Trise, Tfall Ton, Toff Transients 1 dB Compression Input IP3 Input IP2 Vcc Vee Icc — 10% to 90% 50% Control to 90/10% RF In-Band (peak-peak) Input Power Input Power For two-tone Input Power Up to +5 dBm For two-tone Input Power Up to +5 dBm — — Vcc = 4.5 to 5.5V Vctl = 0 to 0.8V, or Vcc – 2.1V to Vcc Vee = -5.0 to -8.0V Logic 0 (TTL) Logic 1 (TTL) 0 to 0.8V 2.0 to 5.0V DC - 2.0 GHz — — — 0.05 GHz 0.5 - 2.0 GHz 0.05 GHz 0.5 - 2.0 GHz 0.05 GHz 0.5 - 2.0 GHz — — — Iee Vctl Vctl Input Leakage Current (Low) Input Leakage Current (High) — — — — — mA V V A A — 0.0 2.0 — — — — — — — 1.0 0.8 5.0 1.0 1.0 1. All specifications apply when operated with bias voltages of +5V for Vcc and –5.0V for Vee. 2. This attenuator is guaranteed monotonic. 2 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information. RoHS Compliant Digital Attenuator 31.5 dB, 6-Bit, TTL Driver, DC-2.0 GHz Absolute Maximum Ratings 3,4 Parameter Max Input Power 0.05 GHz 0.5 - 2.0 GHz Supply Voltages Vcc Vee Control Voltage 5 Operating Temperature Storage Temperature 3. 4. 5. AT-107-PIN V7 Recommended PCB Configuration Absolute Maximum +27 dBm +34 dBm +5.5V -8.5V -0.5V to Vcc +0.5V -55°C to +125°C -65°C to +150°C Exceeding any one or combination of these limits may cause permanent damage to this device. M/A-COM does not recommend sustained operation near these survivability limits. Standard CMOS TTL interface, latch-up will occur if logic signal is applied prior to power supply. Truth Table (Digital Attenuator) Control Inputs C6 0 0 Handling Procedures Please observe the following precautions to avoid damage: C5 0 0 0 0 0 1 0 1 C4 0 0 0 0 1 0 0 1 C3 0 0 0 1 0 0 0 1 C2 0 0 1 0 0 0 0 1 C1 0 1 0 0 0 0 0 1 Attenuation Reference 0.5 dB 1 dB 2 dB 4 dB 8 dB 16 dB 31.5 dB Static Sensitivity Gallium Arsenide Integrated Circuits are sensitive to electrostatic discharge (ESD) and can be damaged by static electricity. Proper ESD control techniques should be used when handling these devices. 0 0 0 0 1 1 Typical Performance Curves Insertion Loss vs. Frequency + 8 5 °C 5.0 + 2 5 °C - 5 5 °C 0 = TTL Low; 1 = TTL High Attenuation Accuracy vs. Frequency Deviation from Nominal Atten (dB) 1 dB 0.60 0.40 0.20 0.00 - 0.20 - 0.40 - 0.60 0.0 0.5 1.0 1.5 2.0 4 dB 2 dB 0 . 5 dB Insertion Loss (dB) 4.0 3.0 2.0 1.0 0 .0 0.0 0.5 1.0 1.5 2.0 Frequency (GHz) Frequency (GHz) 3 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information. RoHS Compliant Digital Attenuator 31.5 dB, 6-Bit, TTL Driver, DC-2.0 GHz Typical Performance Curves Attenuation Accuracy vs. Frequency 8 dB 16 dB 3 1. 5 dB AT-107-PIN V7 RF1 VSWR vs. Frequency 1 dB 2 4 dB 8 & 16 dB Re f Loss & 0 . 5 dB Deviation from Nominal Atten (dB) 0.80 0.40 1.8 0.00 VSWR 0.0 0.5 1.0 1.5 2.0 1.6 1.4 - 0.40 1.2 - 0.80 Frequency (GHz) 1 0.0 0.5 1.0 1.5 2.0 Frequency (GHz) RF2 VSWR vs. Frequency Lead-Free, CR-13 Ceramic Package† 16 dB Re f Loss & 0 . 5 dB 1 & 2 dB 2 1.8 4 dB 8 dB VSW R 1.6 1.4 1.2 1 0.0 0.5 1.0 1.5 2.0 Frequency (GHz) † Reference Application Note M538 for lead-free solder reflow recommendations. 4 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
