Digital Attenuator, 15 dB, 4-Bit, TTL Driver, DC - 3 GHz
V 3.00
AT-213
Features
n Attenuation: 1 dB steps to 15 dB n Temperature Stability: ± 0.18 dB from –55°C to +85°C n n n n
CR-11
Typical Low DC Power Consumption Hermetic Surface Mount Package Integral TTL Driver 50 Ohms Nominal Impedance
Description
M/A-COM’s AT-213 is a 4-bit, 1 dB step digital attenuator in a hermetically sealed ceramic 16-lead surface mount package. The AT-213 is ideally suited for use where high accuracy, fast switching, very low power consumption and low intermodulation products are required. Typical applications include dynamic range setting in a precision receiver circuits and other gain/leveling control circuits. Environmental screening is available. Contact the factory for information.
Electrical Specifications: TA = -55°C to +85°C 1
Parameter Reference Insertion Loss Test Conditions — Frequency DC - 0.5 GHz DC - 1.0 GHz DC - 2.0 GHz DC - 3.0 GHz DC - 2.0 GHz DC - 3.0 GHz DC - 2.0 GHz DC - 3.0 GHz — — — — 0.05 GHz 0.5 - 3.0 GHz 0.05 GHz 0.5 - 3.0 GHz 0.05 GHz 0.5 - 3.0 GHz — — Units dB dB dB dB Min — — — — Typ — — — — Max 1.7 1.9 2.2 2.5
Attenuation Accuracy 2
Any Single Bit
Any Combination of Bits
± (0.15 dB +3% of atten setting in dB) dB ± (0.2 dB +3% of atten setting in dB) dB Or ± 0.4 dB, whichever is greater ± (0.2 dB +3% of atten setting in dB) dB ± (0.2 dB +3% of atten setting in dB) dB Or ± 0.4 dB, whichever is greater Ratio ns ns mV dBm dBm dBm dBm dBm dBm V V — — — — — — — — — — 4.5 -8.0 — 9 40 30 +22 +28 +40 +50 +45 +68 5.0 — 1.6:1 — — — — — — — — — 5.5 -5.0
VSWR Trise, Tfall Ton, Toff Transients 1 dB Compression Input IP3 Input IP2 Vcc Vee
— 10% to 90% 50% Control to 90/10% RF In-Band (peak-peak) Input Power Input Power For two-tone Input Power Up to +5 dBm For two-tone Input Power Up to +5 dBm — —
1. All specifications apply when operated with bias voltages of +5V for Vcc and –5.0V for Vee. 2. This attenuator is guaranteed monotonic.
Digital Attenuator, 15 dB, 4-Bit, TTL Driver, DC - 2 GHz
AT-213
V 3.00
Electrical Specifications: TA = -55°C to +85°C
Parameter Icc Iee Vctl Vctl Input Leakage Current (Low) Input Leakage Current (High) Test Conditions Vcc = 4.5 to 5.5V Vctl = 0 to 0.8V, or Vcc –2.1V to Vcc Vee = -5.0 to -8.0V Logic 0 (TTL) Logic 1 (TTL) 0 to 0.8V 2.0 to 5.0V Frequency — — — — — — Units mA mA V V µA µA Min — — 0.0 2.0 — — Typ — — — — — — Max 4.0 1.0 0.8 5.0 1.0 1.0
Absolute Maximum Ratings 3
Parameter Max Input Power 0.5 GHz 0.5 - 3.0 GHz Supply Voltages Vcc Vee Control Voltage
4
Truth Table
Control Inputs C4 C3 0 0 0 1 0 1 C2 0 0 1 0 0 1 1 = TTL High C1 0 1 0 0 0 1 Attenuation Reference 1 dB 2 dB 4 dB 8 dB 15 dB
Absolute Maximum +27 dBm +34 dBm +5.5V -8.5V -0.5V to Vcc +0.5V -55°C to +125°C -65°C to +150°C
0 0 0 0 1 1 0 = TTL Low
Operating Temperature Storage Temperature
3. Operation of this device above any one of these parameters may cause permanent damage. 4. Standard CMOS TTL interface, latch-up will occur if logic signal is applied prior to power supply.
Functional Schematic (Top View)
RF2
8 dB
RF1 GND GND
4 dB
GND GND GND Vee Vcc C4
1 dB 2 dB
GND GND C1 GND Orientation Mark C2 PIN 1
Specifications subject to change without notice. n North America: Tel. (800) 366-2266 n Asia/Pacific: Tel.+81-44-844-8296, Fax +81-44-844-8298 n Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020
Visit www.macom.com for additional data sheets and product information.
2
Digital Attenuator, 15 dB, 4-Bit, TTL Driver, DC - 2 GHz Typical Performance Curves
AT-213
V 3.00
Ref. Insertion Loss vs. Frequency
+85°C 2.5 +25°C -55°C
Attenuation Accuracy vs. Frequency
1 dB 2 dB 4 dB 8 dB Full Attenuation
Deviation from Nominal Atten (dB)
0.60 0.40 0.20 0.00 -0.20 -0.40 -0.60 0.0 0.5 1.0 1.5 2.0 2.5 3.0
Insertion Loss (dB)
2
1.5
1
0.5
0 0.0 0.5 1.0 1.5 2.0 2.5 3.0
Frequency (GHz)
Frequency (GHz)
RF1 VSWR vs. Frequency
1 dB 1.6 1.5 1.4 2 dB 4 dB 8 dB Reference Loss State
1.6 1.5 1.4
RF2 VSWR vs. Frequency
1 dB 2 dB 4 dB 8 dB Reference Loss State
VSWR
1.3 1.2 1.1 1.0 0.0 0.5 1.0 1.5 2.0 2.5 3.0
VSWR
1.3 1.2 1.1 1 0.0 0.5 1.0 1.5 2.0 2.5 3
Frequency (GHz)
Frequency (GHz)
Ordering Information
Part Number AT-213 PIN Package CR-11
Specifications subject to change without notice. n North America: Tel. (800) 366-2266 n Asia/Pacific: Tel.+81-44-844-8296, Fax +81-44-844-8298 n Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020
Visit www.macom.com for additional data sheets and product information.
3
