Digital Attenuator, 1 Bit, 10 dB Step DC - 2.0 GHz
Features
• Single 10 dB Step • Low Loss: 0.3 dB @ 900 MHz • Low Cost SOT-25 Package
AT-266 V4
Functional Block Diagram
Description
M/A-COM’s AT-266 is a 1 bit, 10 dB step GaAs MMIC digital attenuator in a low cost SOT-25 surface mount plastic package. The AT-266 is ideally suited for use where high accuracy, very low power consumption and low intermodulation products are required. Typical applications include radio, wireless LANs, GPS equipment and other gain/level control circuits. The AT-266 is fabricated using a mature GaAs MMIC process featuring full chip passivation for increased performance and reliability.
Pin Configuration
Pin No. Function
RF1 GND RF2 V1 V2
Description
RF In/Out RF Ground RF In/Out Control Voltage Control Voltage
Ordering Information
Part Number
AT-266 AT-266TR
1 2
Package
Bulk Packaging 1000 piece reel
3 4 5
Note: Reference Application Note M513 for reel size information.
Truth Table 3,4,5
V1 V2
1 0
Attenuation State
10 dB Insertion Loss
Absolute Maximum Ratings 1,2
Parameter
Input Power 50 MHz 500 - 2000 MHz Control Voltage Operating Temperature Storing Temperature
0 1
Absolute Maximum
+27 dBm +34 dBm -8.5 V < Vc < +8 V -40°C to +85°C -65°C to +150°C
3. For positive voltage control, external DC blocking capacitors are required on all RF ports (pins 1, 2 and 3). 4. Differential voltage, V(state 1) - V(state 0), must be +2.8 V minimum and less than 8 V. 5. 0 = -8 V to 0.2 V, 1 = -0.2 V to 8 V
1. Exceeding any one or combination of these limits may cause permanent damage to this device. 2. M/A-COM does not recommend sustained operation near these survivability limits.
1
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information.
• North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
Digital Attenuator, 1 Bit, 10 dB Step DC - 2.0 GHz
Electrical Specifications: TA = 25°C, VC = 0 V / -3 V, Z0 = 50 Ω
Parameter
Insertion Loss Attenuation VSWR IP3 P1dB Trise, Tfall Ton, Toff Transients Control Current
AT-266 V4
Test Conditions
0 - 1 GHz 1 - 2 GHz DC - 1 GHz 1 - 2 GHz 0 - 2 GHz 2 Tone @ 0 dBm, 5 MHz spacing 1 GHz 10% to 90% RF, 90% to 10% RF 50% Control to 90% RF, 50% Control to 10% RF In Band │Vc│ = 3 V
Units
dB dB dB dB Ratio dBm dBm nS nS mV µA
Min.
— — 9.6 9.5 — 42 23 — — — —
Typ.
0.3 0.5 10 10 1.4:1 50 28 5 10 6 25
Max.
0.45 0.7 10.4 10.5 1.5:1 — — 20 25 10 —
SOT-25 Plastic Package
Handling Procedures
Please observe the following precautions to avoid damage:
Static Sensitivity
Gallium Arsenide Integrated Circuits are sensitive to electrostatic discharge (ESD) and can be damaged by static electricity. Proper ESD control techniques should be used when handling these devices.
2
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information.
• North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
Digital Attenuator, 1 Bit, 10 dB Step DC - 2.0 GHz
Typical Performance Curves (39 pF capacitors used for positive voltage control)
Insertion Loss (Positive Control)
1.0
+25°C -40°C +85°C
AT-266 V4
Insertion Loss (Negative Control)
1.0
0.8
0.8
+25°C -40°C +85°C
0.6
0.6
0.4
0.4
0.2
0.2
0.0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
0.0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
Frequency (GHz)
Frequency (GHz)
Relative Attenuation (Positive Control)
11.0
+25°C -40°C +85°C
Relative Attenuation (Negative Control)
11.0
+25°C -40°C +85°C
10.5
10.5
10.0
10.0
9.5
9.5
9.0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
9.0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
Frequency (GHz)
Frequency (GHz)
Return Loss (Reference State)
40
Positive Control Negative Control
Return Loss (10 dB State)
40
Positive Control Negative Control
30
30
20
20
10
10
0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
Frequency (GHz)
3
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information.
Frequency (GHz)
• North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
