Voltage Variable Absorptive Attenuator 35 dB, DC - 2.0 GHz
Features
• • • • • • • 35 dB Voltage Variable Attenuation at 1 GHz Single Voltage Control: 0 to -4 Volts Low DC Power Consumption Nanosecond Switching Speed Temperature Range: -40°C to +85°C SOIC-14 Plastic Package Tape and Reel Packaging Available
AT-635 V6
Functional Schematic
14 13 12 11 10 9 8
Description
M/A-COM’s AT-635 is a GaAs MMIC voltage variable absorptive attenuator in a low cost SOIC 14-lead surface mount plastic package. The AT-635 is ideally suited for use where attenuation fine tuning, fast switching and very low power consumption are required. Typical applications include radio, cellular, GPS equipment and other automatic gain/level control circuits. The AT-635 is fabricated with a monolithic GaAs MMIC using a mature 1-micron process. The process features full chip passivation for increased performance and reliability.
1
2
3
4
5
6
7
Pin Configuration
Pin No.
1 2 3 4 5 6
Function
VC Ground Ground Ground Ground Ground Ground
Pin No.
8 9 10 11 12 13 14
Function
RF2 Ground Ground Ground Ground Ground RF1
Ordering Information
Part Number
AT-635 AT-635TR
7
Package
SOIC 14-Lead Plastic Package Tape and Reel
Absolute Maximum Ratings 1,2
Parameter
Input Power Control Voltage Operating Temperature Storing Temperature
Note: Reference Application Note M513 for reel size information.
Absolute Maximum
+21 dBm -8.5 V < VC < +5 V -40°C to +85°C -65°C to +150°C
1. Exceeding any one or combination of these limits may cause permanent damage to this device. 2. M/A-COM does not recommend sustained operation near these survivability limits.
1
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information.
• North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
Voltage Variable Absorptive Attenuator 35 dB, DC - 2.0 GHz
Electrical Specifications: TA = 25°C, Z0 = 50 Ω
Parameter
Insertion Loss
AT-635 V6
Test Conditions3
DC - 0.5 GHz 0.5 - 1.0 GHz 1.0 - 2.0 GHz 10 dB Attenuation – DC - 2.0 GHz 20 dB Attenuation – DC - 2.0 GHz 30 dB Attenuation – DC - 2.0 GHz
Units
dB dB dB dB dB dB Ratio
Min.
— — — — — — — — — — — — — —
Typ.
6.7 7.2 7.5 + 1.0 + 1.2 + 1.2 2.0:1 2 4 30 — — 34 47
Max.
7.0 7.4 7.8 + 1.3 + 1.5 + 1.5 — — — — 13 21 — —
Flatness (Peak to Peak) VSWR Trise, Tfall Ton, Toff Transients Power Handling IP2
10% to 90% RF, 90% to 10% RF 50% Control to 90% RF, 50% Control to 10% RF In Band Linear Operation Absolute maximum Input Power 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (For two-tone Input Power Up to +5 dBm) 0.05 GHz 0.5 - 2.0 GHz Measured Relative to Input Power (For two-tone Input Power Up to +5 dBm)
nS nS mV dBm dBm dBm dBm
IP3
dBm dBm
18 18.5
31 4 36 4
— —
3. Control voltage: 0 to -4 volts @ 20 µA typical. 4. For levels above 6 dB attenuation. For levels below 6 dB, the minimum specification numbers apply.
SOIC-14
Handling Procedures
Please observe the following precautions to avoid damage:
Static Sensitivity
Gallium Arsenide Integrated Circuits are sensitive to electrostatic discharge (ESD) and can be damaged by static electricity. Proper ESD control techniques should be used when handling these devices.
2
M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information.
• North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
Voltage Variable Absorptive Attenuator 35 dB, DC - 2.0 GHz
Typical Performance Curves
Insertion Loss vs. Frequency
12
+25°C -40°C +85°C
AT-635 V6
Attenuation vs. Control Voltage, F = 1 GHz
40
10
30 8
6
20
4 10 2
0 0.0
0.5
1.0
1.5
2.0
2.5
3.0
0 -3.0
-2.5
-2.0
-1.5
-1.0
-0.5
0.0
Frequency (GHz)
Control Voltage (V)
Attenuation vs. Frequency
50
VSWR vs. Frequency
3.5
Insertion Loss 5 dB Atten 10 dB Atten 35 dB Atten
40
3.0
30
2.5
20
2.0
10
1.5
0 0.0
1.0
0.5 1.0 1.5 2.0 2.5 3.0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
Frequency (GHz)
Frequency (GHz)
3
