CH-132

20 dB, Bi-Directional Coupler, 1 - 1000 MHz Features • Broad Frequency Range • Constant Coupling—Within ± 0.5 dB Max • VSWR: 1.3:1 Max • CH-132 V3 C-8 Description Bi-Directional Couplers offer the ability to couple the power in two directions while maintaining directivity. Electrical Specifications1: TA = -55°C to +85°C Parameter Coupling Coupling Flatness VSWR Directivity Main Line Loss 2 Test Conditions Input to Output — All Ports Both Directions — Frequency 1-1000 MHz 10 - 500 MHz 1 - 1000 MHz 10 - 500 MHz 1 - 1000 MHz 10 - 500 MHz 1 - 1000 MHz 10 - 500 MHz 1 - 1000 MHz Units dB dB dB Ratio Ratio dB dB dB dB Min 19.0 — — — — 25 20 — — Typ 20.0 — — — — — — — — Max 21.0 ± 0.25 ± 0.5 1.2:1 1.3:1 — — 0.5 0.7 1. All specifications apply with 50 ohm source and load impedance. 2. Includes theoretical power split. This product contains elements protected by United States Patent umber 3,426,298. 1 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information. 20 dB, Bi-Directional Coupler, 1 - 1000 MHz Functional Diagram Ordering Information Part Number CH-132 BNC CH-132 N CH-132 SMA CH-132 TNC Package Connectorized Connectorized Connectorized Connectorized CH-132 V3 Typical Performance Curves 2 M/A-COM Inc. and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. M/A-COM makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does M/A-COM assume any liability whatsoever arising out of the use or application of any product(s) or information. • North America Tel: 800.366.2266 / Fax: 978.366.2266 • Europe Tel: 44.1908.574.200 / Fax: 44.1908.574.300 • Asia/Pacific Tel: 81.44.844.8296 / Fax: 81.44.844.8298 Visit www.macom.com for additional data sheets and product information.
