CH-26

HARTMAN Aerospace Power Products DC Current Sensor Features: • Two Separate Sensors in One Package • SPST Main Contacts • Current Operated • Hermetically Sealed • 28 VDC • 1 Amp • High Reliability • Meets many requirements of MIL-R-6106 CH-26 SPST, 1 Amp, 28 VDC CONTACTOR CONFIGURATION Notes: Dimensions for this product are expressed in inches. Multiply values by 25.4 for millimeters. PRODUCT SPECIFICATIONS Specification for Complete Unit Construction Coil Data Duty Cycle Minimum Operating Cycles Environmental Data: Operating Temperature Vibration Weight Maximum Specifications for Each Relay Contact Data: Contacts Contact Rating Coil Data: Pick-Up Drop-Out Operating Current: In-Rush Maximum Two Relays Packaged Metal Case, Potted Assembly with Contacts Hermetically Sealed Continuous (Each Relay) 50,000 (Each Relay) -55°C to +71°C 20 G to 2000 Hz 8 Oz. Both Relays the Same SPST 1 Amp at 28 VDC Lamp Load 0.75 Amp Maximum, 400 Hz 0.10 Amp Minimum, 400 Hz Continuous Operating Current of 7.5 Amps Max, 400 Hz 37.5 Amps, 400 Hz For factory-direct application assistance, contact the HARTMAN product team at (419) 521-9500, Fax (419) 526-2749. © 2004 by Tyco Electronics Corporation. All Rights Reserved. HARTMAN and TYCO are trademarks. Catalog (web doc only) Revised 5-04 www.tycoelectronics.com Dimensions are in inches and millimeters unless otherwise specified. Values in brackets are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. USA: 1-800-522-6752 Canada: 1-905-470-4425 Mexico: 01-800-733-8926 C. America: 52-55-5-729-0425 South America: 55-11-3611-1514 Hong Kong: 852-2735-1628 Japan: 81-44-844-8013 UK: 44-141-810-8967
