CH-27

HARTMAN Aerospace Power Products DC Current Sensor Features: • 2PDT Main Contacts • Current Operate • Hermetically Sealed • 28 VDC • .75 Amp • High Reliability • Meets many requirements of MIL-R-6106 • Light Weight Construction CH-27 2PDT, .75 Amp, 28 VDC CONTACTOR CONFIGURATION Dimensions for this product are expressed in inches. Multiply values by 25.4 for millimeters. PRODUCT SPECIFICATIONS Construction Contacts: Rating Coil Data: Duty Cycle Pick-Up Drop-Out Continuous Operating Current In-Rush Environmental Data: Operating Temperature Vibration Weight Maximum Minimum Operating Cycles Metal Case, Potted Assembly with Contacts Hermetically Sealed 2PDT (Simultaneous Transfer Not Required) 1 Amp, 28 VDC, Lamp Load Continuous 0.75 Amp Maximum, 400 Hz 0.10 Amp Minimum, 400 Hz 12 Amps Maximum, 400 Hz 60 Amps Maximum -55°C to +71°C 20 G to 2000 Hz 7 Oz. 50,000 Notes: For factory-direct application assistance, contact the HARTMAN product team at (419) 521-9500, Fax (419) 526-2749. © 2004 by Tyco Electronics Corporation. All Rights Reserved. HARTMAN and TYCO are trademarks. Catalog (web doc only) Revised 5-04 www.tycoelectronics.com Dimensions are in inches and millimeters unless otherwise specified. Values in brackets are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. USA: 1-800-522-6752 Canada: 1-905-470-4425 Mexico: 01-800-733-8926 C. America: 52-55-5-729-0425 South America: 55-11-3611-1514 Hong Kong: 852-2735-1628 Japan: 81-44-844-8013 UK: 44-141-810-8967
