RJ11-2X_11

Corcom Product Guide Unfiltered Modular Jacks Catalog: 1654001 Issue Date: 06.2011 X Series UL Recognized CSA Certified RJ45 RJ11 X S er i es • Unfiltered standard jack • RJ11 or RJ45 • 2, 4, 6 or 8 loaded contacts • Available unshielded or shielded with board grounded shield or spring fingered panel ground interface Specifications Contacts: Material: Phosphor Bronze Plating: 50 microinches gold Barrier underplating: 100 microinches nickel Resistance: Initial: 20 m max. After 500 mating cycles: 30 m max. Shield Material: Housing Material: Tin-plated copper alloy Glass-filled polyester (UL94V-0) 1000 VAC for 60 seconds 1 lb. minimum 20 lb. minimum Dielectric Withstanding Voltage: Line to Line and Line to Ground: Printed Circuit Board Retention: Before soldering: After soldering: Shield 1 Shield 2 Available Part Numbers RJ11-2X RJ11-4X RJ11-6X RJ45-6X RJ45-8X RJ45-8X1 RJ45-8X2 Model dimensions and PC board layout on pages 255-259 252 Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com Corcom Product Guide Model Dimensions Catalog: 1654001 Issue Date: 06.2011 L, LC, LCT and X Series RJ Jack Dimensions RJ11 – No Shield .620 15.75 .520 13.21 .810 20.57 RJ11 – Style 2 Shield .900 22.86 .800 20.32 .590 14.99 .040 1.02 .195 4.95 .165 4.19 .780 19.81 .04 1.02 .195 4.95 .165 4.19 .165 4.19 .322 8.19 .395 10.03 .322 8.18 .485 12.32 6 4 2 5 3 1 .520 13.21 6 4 2 5 3 1 .540 13.72 RJ11-2L-S RJ11-4L-S RJ11-6L-S Part No. RJ11-2L-B RJ11-4L-B RJ11-6L-B RJ11-2X RJ11-4X RJ11-6X RJ11-2LC2-S RJ11-4LC2-S RJ11-6LC2-S Part No. RJ11-2LC2-B RJ11-4L2-S RJ11-4LC2-B RJ11-6L2-S RJ11-6LC2-B RJ11-4L2-B RJ11-6L2-B RJ11-6LCT2-S RJ11-6LCT2-B RJ11 – Style 1 Shield .840 21.34 .900 22.86 .860 21.84 RJ11 – PC Board Layout With shield .350 8.89 .322 8.18 .250 6.35 0.76 ± .003 1.93 ± .08 0.030 +.008 / -.003 .76 +.20 / - .08 (6 places) Edge of Board .165 4.19 1 2 3 4 5 6 .780 19.81 .04 1.02 .195 4.95 .165 4.19 .400 10.16 6 .075 1.91 .050 1.27 (5 places) .322 8.18 .485 12.32 Signal Line Products 6 4 2 5 3 1 .540 13.72 .075 1.91 .210 5.33 .345 8.76 .128 ± .003 Dia. 3.25 ± .08 (2 holes) RJ11-2LC1-S RJ11-4LC1-S RJ11-6LC1-S Part No. RJ11-2LC1-B RJ11-4L1-S RJ11-4LC1-B RJ11-6L1-S RJ11-6LC1-B RJ11-4L1-B RJ11-6L1-B RJ11-6LCT1-S RJ11-6LCT1-B For all RJ11 L, LC, LCT and X Series Models Shown from Component Side        255 Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com 255 Corcom Product Guide Model Dimensions (continued) Catalog: 1654001 Issue Date: 06.2011 L, LC, LCT and X Series RJ Jack Dimensions (continued) RJ45 – No Shield .700 17.78 .600 15.24 .810 20.57 RJ45 – Style 2 Shield .900 22.86 .800 20.32 .540 13.72 .04 1.02 .195 4.95 .165 4.19 .780 19.81 .04 1.02 .195 4.95 .165 4.19 .165 4.19 .322 8.18 .395 10.03 .322 8.18 .485 12.32 8 7 6 5 4 3 2 1 7 6 5 4 3 2 1 .620 15.75 8 Part No. RJ45-6L-S RJ45-8L-S RJ45-6L-B RJ45-8L-B RJ45-6X RJ45-8X Part No. RJ45-6LC2-S RJ45-8LC2-S RJ45-6LC2-B RJ45-8LC2-B RJ45-6L2-S RJ45-8L2-S RJ45-6L2-B RJ45-8L2-B RJ45-8LCT2-S RJ45-8LCT2-B RJ45 – Style 1 Shield .920 23.37 .900 22.86 .860 21.84 RJ45 – PC Board Layout .322 8.18 .780 19.81 .04 1.02 .195 4.95 .165 4.19 .165 4.19 .350 8.89 .250 6.35 .076±.003 Dia. 1.93±.08 (4 PLACES) .030 +.008/.003 Dia. .76 +.20/-.08 (8 PLACES) 1 3 .450 11.43 2 4 6 8 .050 1.27 (7 SPACES) 5 7 .322 8.18 .485 12.32 8 7 6 5 4 3 2 1 .620 15.75 .210 5.33 .345 8.76 .090 .050 2.29 1.27 .128±.003 Dia. 3.25±.08 (4 PLACES) RJ45-6LC1-S RJ45-6L1-S RJ45-8LCT1-S Part No. RJ45-8LC1-S RJ45-8L1-S RJ45-8LCT1-B RJ45-6LC1-B RJ45-6L1-B RJ45-8LC1-B RJ45-8L1-B For all RJ45 L, LC, LCT and X Series Models Shown from Component Side        Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com Corcom Product Guide Model Dimensions (continued) Catalog: 1654001 Issue Date: 06.2011 L, LC, LCT and X Series RJ Jack Dimensions (continued) RJH – No Shield .540 13.72 .440 11.18 .810 20.57 RJH – PC Board Layout .322 8.18 .590 14.99 .04 1.02 .350 8.89 .250 6.35 .030 +.008/-.003 Dia. .76 +20/-.08 (4 holes) Edge of board .195 4.95 1 3 2 4 .075 1.91 .050 1.27 (3 Spaces) .300 7.62 .322 8.18 .395 10.03 4 3 2 1 .250 6.35 .128±.003 Dia. 3.25±.08 (2 holes) .350 8.89 Part No. RJH-4-L-B N and Z Series RJ Jack Dimensions RJ11 – Low Profile, No Shield .620 15.75 .520 13.21 .710 18.03 RJ11 Low Profile, Style 3 Shield .910 Max. 23.11 .740 18.80 .485 12.32 .010 .25 .165 4.19 .135 3.43 .515* 13.08 .010 .25 .120 3.05 *to top of shield .135 3.43 .165 4.19 6 Signal Line Products .217 5.51 .400 10.16 .217 5.51 .430 10.92 6 6 4 2 5 3 1 .520 13.21 4 2 5 3 1 .550 13.97 Part No. RJ11-6N-B RJ11-6Z RJ11-6N3-B Part No. RJ11-6Z3        257 Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com 257 Corcom Product Guide Model Dimensions (continued) Catalog: 1654001 Issue Date: 06.2011 N and Z Series RJ Jack Dimensions (continued) RJ11 Low Profile, Style 4 Shield .620 15.75 .740 18.80 RJ45 – Low Profile, No Shield .70 17.78 .60 15.24 .710 18.03 .515* 13.08 .485 12.32 .010 .254 .120 3.05 .010 .25 .135 .165 3.43 4.19 .135 3.5 .165 4.2 *to top of shield .217 5.51 .430 10.92 .217 5.51 .40 10.16 6 4 2 5 3 1 .550 13.97 Part No. RJ11-6N4-B RJ11-6Z4 RJ45-8N-B Part No. RJ45-8N-S RJ45-8Z RJ11 Low Profile, PC Board Layout RJ45 – Low Profile, Style 3 Shield .99 Max. 25.15 .740 18.80 .076±.003 1.93±.08 Dia. (2 PLACES) .217 5.51 .350 8.89 .250 6.35 .515* 13.08 .030 + .008/- .003 Dia. .76 +.20/-.08 (6 PLACES) 1 3 .050 (5 SPACES) 1.27 .120 3.05 .135 .165 3.43 .4.19 2 .400 10.16 4 5 6 *to top of shield .217 5.51 .430 10.92 .080 2.03 .075 1.91 .120 3.05 .128±.003 Dia. 3.25±.08 (2 HOLES) 7 5 8 6 4 3 2 1 .630 16.00 For all RJ11 N and Z Series Models Shown from Component Side RJ45-8N3-B Part No. RJ45-8N3-S RJ45-8Z3        258 Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com Corcom Product Guide Model Dimensions (continued) Catalog: 1654001 Issue Date: 06.2011 N and Z Series RJ Jack Dimensions (continued) RJ45 Low Profile, Style 4 Shield .700 17.78 .740 18.80 RJ45 Low Profile PC Board Layout .515* 13.08 .010 .25 .217 5.51 .076±.003 Dia. 1.93±.08 (2 Places) .135 3.43 .165 4.19 .350 8.89 .250 6.35 1 3 2 4 6 8 .050 (7 Spaces) 1.27 .030 +.008/-.003 Dia. .76 +.20/-.08 (8 Places) .120 3.05 *to top of shield .217 5.51 .430 10.92 .450 11.43 5 7 .095 2.41 8 7 5 3 1 6 4 2 .630 16.00 .120 3.05 .050 1.27 .128±.003 Dia. 3.25±.08 (2 Places) RJ45-8N4-B Part No. RJ45-8N4-S For all RJ45 N and Z Series Models Shown from Component Side RJ45-8Z4        6 Signal Line Products 259 Dimensions are in inches and millimeters unless otherwise specified. Values in italics are metric equivalents. Dimensions are shown for reference purposes only. Specifications subject to change. For email, phone or live chat, please go to te.com/help corcom.com
