S200-2-W1-22-9

CUSTOMER DRAWING 1 3 2 3 4 Product Name S200-1-W1-22-9 S200-2-W1-22-9 S200-3-W1-22-9 S200-4-W1-22-9 S200-5-W1-22-9 Ident. Code S2001R S2002R S2003R S2004R S2005R Product Dimensions øB øC L±1.75 min min (L±0.075) 16.50 1.90 2.67 (0.650) (0.075) (0.105) 16.50 2.67 3.68 (0.650) (0.105) (0.145) 16.50 4.32 5.08 (0.650) (0.170) (0.200) 19.10 5.97 6.48 (0.750) (0.235) (0.255) 19.10 6.98 7.62 (0.750) (0.275) (0.300) øD max 1.90 (0.075) 2.67 (0.105) 4.32 (0.170) 5.97 (0.235) 6.98 (0.275) Cable Dimensions øE øF max min 2.67 0.90 (0.105) (0.035) 3.68 1.40 (0.145) (0.055) 5.08 2.15 (0.200) (0.085) 6.48 3.30 (0.255) (0.130) 7.62 4.30 (0.300) (0.170) øG min 0.50 (0.020) 0.75 (0.030) 1.25 (0.050) 1.80 (0.070) 2.50 (0.100) MATERIALS 1. INSULATION SLEEVE: Heat-shrinkable, transparent blue, radiation cross-linked modified fluoropolymer. 2. SOLDER PREFORM WITH FLUX AND THERMAL INDICATOR: SOLDER: TYPE Sn96 per ANSI / J-STD-006. FLUX: TYPE ROM1 per ANSI / J-STD-004. THERMAL INDICATOR: Fusible ring. 3. MELTABLE RINGS: Environment resistant modified thermoplastic fluoroelastomer. Color: light blue. 4. PRE-INSTALLED LEAD: Stranded silver-plated copper in accordance with SAE-AS22759/91-22-9. Color: white. APPLICATION 1. These parts are designed to provide an environment resistant shield termination on cables, rated for 150°C minimum, meeting the dimensional criteria listed, having silver or nickel-plated shields and insulations compatible with the insert material. 2. Install using Tyco Electronics approved convection or infrared heating tools in accordance with Tyco Electronics process standard RCPS-100-71. When installed with approved convection or infrared heating tools, assemblies will meet the performance requirements of SAE AS83519. Infrared tools are not recommended for use with black cable jackets. 3. Parts shall be marked with identification code per table. 4. Temperature range: -65°C to +200°C. For best results, prepare the cable as shown: “G” is the minimum diameter on which the sleeve will seal. 300 Constitution Dr Menlo Park, CA 94025, U.S.A. TITLE: SOLDERSLEEVE SHIELD TERMINATOR WITH LEADS, IMMERSION RESISTANT, 200 DEG C, ROHS COMPLIANT DOCUMENT NO.: Unless otherwise specified dimensions are in millimeters. [Inches dimensions are shown in brackets] TOLERANCES: 0.00 N/A 0.0 N/A 0 N/A REVISED BY: ANGLES: N/A ROUGHNESS IN MICRON CAGE CODE: Raychem Devices S 200-X-W1-22-9 REV: DATE: Tyco Electronics reserves the right to amend this drawing at any time. Users should evaluate the suitability of the product for their application. ECO NUMBER: C SCALE: SIZE: June 2, 2009 SHEET: YUNGUYEN 06090 Print Date: 2-Jun-09 If this document is printed it becomes uncontrolled. Check for the latest revision. ECO-09-013095 NTS A 1 of 1 © 2005-2009 Tyco Electronics Corporation. All rights reserved.
