216-501-76-62

FILAMENT REPLACEMENT LEDs - Multi-LED Cluster FEATURES 216 SERIES PACK QUANTITY = 1 PIECE Direct replacement for BA22 50 LED Cluster Reverse polarity options availability Polycarbonate lens SPECIFICATIONS Ordering Information & Typical T echnical Characteristics (T a = 25°C) Mean Time Between Failure = 100,000 Hours. PART NUMBER COLOUR Luminous intensity figures refer to the unmodified discrete LED. VOLTAGE Vopr CURRENT lopr LUMINOUS lv@20mA WAVE λp OPERATING T opr STORAGE T stg LENS AC/DC DC INTENSITY LENGTH TEMP TEMP HIGH INTENSITY 216-501-76-62 UNITS Red Water Clear 230Vac 13 mA 11000 mcd 624 nm -40 ~ +85^ 0 -40 ~ +85 0 Yes C C 501 ^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs. How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply © MARL INTERNATIONAL LTD 2007 : DS 030/07 Issue 1 SAMPLES AVAILABLE Page 1 of 2 216 Series Dimensions in mm (Typical) Not to scale TECHNICAL INFORMATION Lamp Base Style BA22 Filament Base Series 216 Metric Equivalent (mm) 26 Maximum Power Dissipation (mW) 2500 DESIGN CONSIDERATIONS Product Evaluation Filament Replacement LEDs have been specifically designed to meet the primary objective of providing improved reliability. As this product range is suitable for both new-build and retro-fit, (sometimes in very old systems), a wide range of illuminated push button switches and lamp holders can be encountered. Due to subjectivity, evaluation of the LED type is recommended, (samples of all standard models are available). Care should teristics such as viewing angle, colour compatibility and on/off contrast ratio. Electro-static Discharge (ESD) Build up of electro-static discharge occurs in many situations involving people moving and handling products. The range of possible situations is be taken to correctly simulate operating ambient light conditions to ensure that the correct device has been selected to maximise viewing charac- very diverse but voltage levels as high as several thousand volts can and do arise in many individual situations. When an operator charged up to these levels handles a ‘static sensitive device’, there is a very probable likelihood that the device will be irreversibly damaged. It is essential that precautions are taken at all stages during manufacture and assembly of these products. Although LEDs were never considered to be static sensi- tive devices, changes in manufacturing technology and materials used to produce higher intensity products over a large range of the wavelength We recommend all users of LED based products follow the guidelines of BS 100015. Power de-rating The forward voltage/current value of an LED is dependant upon the ambient temperature of the environment in which it is operated. Therefore, spectrum have changed this. Marl has an approved system of ESD control from goods in, through production and into final packing and despatch. care must be taken to operate the LED at the correct voltage/current values, depending upon the ambient temperature. Consequently, a recomrating’. mendation regarding operating voltages and currents is given in order to address these temperature effects. This recommendation is termed ‘de- It is usual for forward voltages and currents to be specified for ambient temperature of 25°C. However, because the values of these qualities vary with temperature, Marl should be contacted if the device is to be operated at a temperature significantly higher than 25°C. Marl accept no liability for any product that is operated higher than the stated voltage. Note: All luminous intensity figures refer to the unmodified discrete LED. website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2007 : DS 030/07 Issue 1 SAMPLES AVAILABLE Page 2 of 2
