PANEL INDICATOR LEDs - Ø6.35mm Mounting FEATURES 318 Bi-colour & Tri-colour SERIES Domed fresnel lens styling for wide viewing angle Flying lead terminations available Available as a Red/Amber/Green tri-colour indicator Sealed to IP40 Supplied complete with mounting hardware Product illustrated 318-530-23 PACK QUANTITY = 20 PIECES SPECIFICATIONS Ordering Information & Typical T echnical Characteristics (T a = 25°C) Mean Time Between Failure Typically = 100,000 Hours. PART NUMBER COLOUR LENS Luminous intensity figures refer to the unmodified discrete LED. VOLTAGE CURRENT LUMINOUS WAVE OPERATING STORAGE DC (Vdc) Vopr DC (mA) lopr INTENSITY lv@20mA (mcd) LENGTH λp (nm) TEMP T opr TEMP T stg BI-COLOUR STANDARD INTENSITY 318-530-04 318-530-20 318-530-21 318-530-23 Red/Green Red/Green Red/Green Red/Green Water Clear Water Clear Water Clear Water Clear 2.0/2.2 5/6 12 24-28 20 15/20 20 20 30/25 30/25 30/25 30/25 627/565 627/565 627/565 627/565 -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 Yes Yes Yes Yes TRI-COLOUR STANDARD INTENSITY 318-535-04-35 318-535-20-35 318-535-21-35 318-535-22-35 UNITS 530 & 535 Red/Green Red/Green Red/Green Red/Green Water Clear Water Clear Water Clear Water Clear 2.0/2.2 5/6 12 24-28 Vdc 20 15/20 20 20 mA 60/50 60/50 60/50 60/50 mcd 627/565 627/565 627/565 627/565 nm -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ °C -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 °C Yes Yes Yes Yes ^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs. Appropriate LED numbers shown. How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply © MARL INTERNATIONAL LTD 2007 : DS083/07 Issue 1 SAMPLES AVAILABLE Page 1 of 3 318 Bi-colour and Tri-colour Series Bi-colour Tri-colour MOUNTING HOLE Dimensions in mm (Typical) Not to scale Red dot denotes red anode, green dot denotes green anode. Centre pin cathode on tri-colour version. MATERIALS Body Panel Washer T ermination Pins Retaining Clip Fresnel lens Header Nylon 6 Neoprene Tin on Nickel Plated Phosphor Bronze Spring steel Polycarbonate PTFE PUSH-ON CONNECTORS 909-000-00 is gold plated 910-000-00 is tin plated for use with 318 series. Suitable for wire sizes from 0.15mm² to 0.38mm² cross sectional area. Dual metal contact design provides low contact. and gas tight electrical resistance Dimensions in mm (Typical) Not to scale TECHNICAL CHARACTERISTICS SERIES POWER MAXIMUM REVERSE MAXIMUM CUTOUT 6.35 mm PANEL MOUNTING MINIMUM PANEL MIN/MAX. 318 UNITS 500 DISSIPATION 3 VOLTAGE CENTRES 13.0 mm THICKNESS 9.0 mW Vdc mm OPTIONAL FLYING LEAD TERMINATIONS ORDER SUFFIX 13 13 17 17 CODE SUPPLY VOLTAGE WIRE COLOUR WIRE LENGTH NO/DIAMETER CONDUCTORS OF DIAMETER INSULATION OVER COMMENTS DC Products AC Products DC Products AC Products Red-anode / Black-cathode Brown-live / Blue-neutral Red-anode / Black-cathode Brown-live / Blue-neutral 150mm 150mm 1000mm 1000mm Customised available 7/0.2mm 1.2mm lengths How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2007 : DS 083/07 Issue 1 SAMPLES AVAILABLE Page 2 of 3 318 Series Part numbers also available in the 318 Series: PART NO. COLOUR (Vdc) Vopr VOLTAGE The products listed above illustrate all of the options available to order. These products may have custom modifications that alter their operation 318-502-20-03 318-502-22-03 318-503-21 318-503-22 318-503-22-03 318-503-22-04 318-506-22-03 318-509-22 318-512-21-13 318-512-22-03 318-512-23 318-513-23 318-519-22 318-521-22 318-530-04 318-530-20-50 318-530-22 318-530-22-50 318-535-04 318-535-04-35 318-535-20-35 318-535-21 318-535-21-35 318-535-21-50 318-535-22 318-535-22-13 318-535-22-17 318-535-22-19 318-535-22-35 318-535-22-54 318-535-22-55 318-535-24-35 318-535-71 318-536-21 318-538-22 UNITS Red Red Red Red Red Red Orange Yellow Green Green Green Green Blue Yellow Red/Green Red/Green Red/Green Red/Green Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Green Tri Red/Yellow Tri Red/Green Tri 5/6Vdc 24Vdc 12Vdc 24Vdc 24Vdc 24Vdc 24Vdc 24Vdc 12Vdc 24Vdc 24-28Vdc 24-28Vdc 24Vdc 24Vdc 20mA 5/6Vdc 24Vdc 24Vdc 20mA 20mA 5/6Vdc 12Vdc 12Vdc 12Vdc 24Vdc 24Vdc 24Vdc 24Vdc 24Vdc 24Vdc 24Vdc 48Vdc 12Vac 12Vdc 24Vdc beyond the generic information contained within this datasheet. Please contact sales for further information. How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2007 : DS 083/07 Issue 1 SAMPLES AVAILABLE Page 3 of 3
