PANEL INDICATOR LEDs - Ø6.35mm Mounting FEATURES 352 SERIES Snap-In Supplied with 150mm flying lead terminations as standard PACK QUANTITY = 20 PIECES Sealed to IP40 352-535-04 can be used as a tri colour device Product illustrated 352-535-04 SPECIFICATIONS Ordering Information & Typical T echnical Characteristics (T a = 25°C) Mean Time Between Failure Typically = 100,000 Hours. PART NUMBER COLOUR LENS Luminous intensity figures refer to the unmodified discrete LED. VOLTAGE Vopr CURRENT lopr LUMINOUS lv@20mA WAVE λp OPERATING T opr STORAGE T stg DC DC INTENSITY LENGTH TEMP TEMP STANDARD INTENSITY 352-505-04 352-511-04 352-514-04 352-535-04 352-581-20 352-582-20 352-583-20 Red Yellow Green Red/Green Red Yellow Green Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused 2.0* 2.1* 2.2* 2.0/2.2* 5 5 5 20 20 20 20 13 13 11.5 60 40 40 60/50 50@13mA 20@13mA 20@11.5mA 627 590 565 627/565 627 590 565 -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ -40 ~ +85^ -40 ~ +70^ -40 ~ +70^ -40 ~ +70^ -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 Yes Yes Yes Yes Yes Yes Yes STANDARD INTENSITY 352-501-04 352-521-04 352-532-04 352-930-04 352-997-04 UNITS 997 *Typical emission colour cold white 0.283 0.330 0.330 Red Yellow Green Blue Cold White Water Clear Water Clear Water Clear Water Clear Water Clear 1.85* 2.2* 3.5* 3.6* 3.6* Vdc 20 20 20 20 20 mA 2700 6100 11600 3460 7800 mcd 660 595 525 470 *see below nm -40 ~ +85^ -40 ~ +85^ -30 ~ +85^ -30 ~ +85^ -30 ~ +85^ 0 -40 ~ +85 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 0 Yes Yes Yes Yes Yes C C Intensities (lv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch. x y 0.296 0.276 0.305 0.360 0.318 ^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs. shown. Refer to page 3. Appropriate LED numbers How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply © MARL INTERNATIONAL LTD 2007 : DS076/07 Issue 1 SAMPLES AVAILABLE Page 1 of 3 352 Series MOUNTING HOLE Dimensions in mm (Typical) Not to scale Anode termination indicated by long tag. Mounting hole to be clean an burr free MATERIALS Body Panel Washer T ermination Pins Retaining Clip Lens Header Nylon 6 N/A Tin on Nickel Plated Phosphor Bronze N/A Epoxy PTFE TECHNICAL CHARACTERISTICS SERIES POWER MAXIMUM REVERSE MAXIMUM CUTOUT PANEL MOUNTING MINIMUM PANEL MIN/MAX. DISSIPATION 352 UNITS 500 mW VOLTAGE 3 Vdc CENTRES 9.0 mm THICKNESS 3.0 mm 6.35 mm OPTIONAL FLYING LEAD TERMINATIONS ORDER SUFFIX 13 13 17 17 CODE SUPPLY VOLTAGE WIRE COLOUR WIRE LENGTH NO/DIAMETER CONDUCTORS OF DIAMETER INSULATION OVER COMMENTS DC Products AC Products DC Products AC Products Red-anode / Black-cathode Brown-live / Blue-neutral Red-anode / Black-cathode Brown-live / Blue-neutral 150mm 150mm 1000mm 1000mm Customised available 7/0.2mm 1.2mm lengths PROTECTION DIODE SUFFIX 01 ORDER CODE CIRCUIT COMMENTS Available on all indicators except Bi-Colour devices and when diode test is specified. How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2007 : DS 076/07 Issue 1 SAMPLES AVAILABLE Page 2 of 3 352 Series Part numbers also available in the 352 Series: PART NO. COLOUR VOLTAGE (Vdc) Vopr PART NO. COLOUR VOLTAGE (Vdc) Vopr 352-503-04 352-503-04-15 352-503-04-50 352-505-04-52 352-505-12-50 352-509-04 352-509-04-15 352-509-04-50 352-511-04-53 352-512-04 352-512-04-15 352-512-04-50 352-512-04-51 352-512-04-52 352-530-04 352-535-04-15 352-535-04-53 352-535-04-54 352-535-04-56 UNITS Red Red Red Red Red Yellow Yellow Yellow Yellow Green Green Green Green Green Red/Green Red/Green/Amber Red/Green/Amber Red/Green/Amber Red/Green/Amber 20mA 20mA 20mA 20mA 24Vdc 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 20mA 352-535-04-57 352-538-04-50 352-549-04 352-581-20-15 352-581-20-52 352-582-20-15 352-582-20-50 352-582-20-51 352-583-20-15 352-583-20-50 352-583-20-54 352-583-20-55 352-584-21 352-584-21-50 352-585-21 352-585-21-50 352-586-21 352-586-21-50 352-586-21-51 UNITS Red/Green/Amber Red/Green/Amber Green/Yellow Red Red Yellow Yellow Yellow Green Green Green Green Red Red Yellow Yellow Green Green Green 20mA 20mA 20mA 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 5/6Vdc 12Vdc 12Vdc 12Vdc 12Vdc 12Vdc 12Vdc 12Vdc The products listed above illustrate all of the options available to order. These products may have custom modifications that alter their operation beyond the generic information contained within this datasheet. Please contact sales for further information. De-rating Information 505, 511, 532, 930 & 997 514 521 532 501 How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 © MARL INTERNATIONAL LTD 2007 : DS 076/07 Issue 1 SAMPLES AVAILABLE Page 3 of 3
