507-512-21

PROFESSIONAL LED INDICATORS Ø8.1mm Mounting FEATURES Robust bright nickel plated brass housing 507 SERIES PACK QUANTITY = 10 PIECES Low profile styling, sunlight readable LEDs Sealed to IP67 Suitable for high vibration applications Internal reverse protection diode fitted as standard in all voltage models. SPECIFICATION Ordering Information & Typical T echnical Characteristics (T a = 25°C) Mean Time Between Failure = 100,000 Hours. PART NUMBER COLOUR Luminous intensity figures refer to the unmodified discrete LED. VOLTAGE CURRENT LUMINOUS WAVE OPERATING STORAGE LENS DC (Vdc) Vopr DC (mA) lopr INTENSITY lv@20mA (mcd) LENGTH λp (nm) TEMP T opr TEMP T stg HIGH INTENSITY 507-501-21 507-521-21 507-532-21 507-930-21 507-997-21 507-501-23 507-521-23 507-532-23 507-930-23 507-997-23 UNITS Red Yellow Green Blue Cool White Red Yellow Green Blue Cool White Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused Colour Diffused 12 12 12 12 12 24-28 24-28 24-28 24-28 24-28 Vdc 19 19 20 20 20 20 20 20 20 20 mA 11000 16000 23000 7000 14000 11000 16000 23000 7000 14000 mcd 643 591 527 470 *see below 643 591 527 470 *see below nm -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ -40 ~ +95^ °C -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 -40 ~ +100 °C Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Other voltages AC/DC available. Please contact our Technical Sales. ^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs. 997F-C *Typical emission colour cool white 0.361 0.356 0.264 Intensities (lv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch. x y 0.245 0.229 0.385 0.351 0.220 How to Order: website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply © MARL INTERNATIONAL LTD 2008 : DS 034/06 Issue 4 SAMPLES AVAILABLE Page 1 of 3 507 Series Mounting Hole Dimensions in mm (Typical) Not to scale Anode termination indicated by red sleeve Mounting hole to be clean an burr free MATERIALS Body Brass to BS 2874 CZ121 Nickel plated to BS 1224 Nut Brass to BS 2874 CZ121 nickel plated to BS 1224 Panel Seal T ermination Viton Brass to BS 2874 CZ108 Copper flash undercoat with silver flash finish Lock Washer Fresnel lens Encapsulation Zinc plated steel Polycarbonate PC5430 resin PUSH-ON CONNECTORS 925-000-00 is brass tin plated. Dimensions in mm (Typical) Not to scale For use with 507 series lamps. TECHNICAL CHARACTERISTICS SERIES MAXIMUM DISSIPATION 507 700 mw * = current version POWER MAXIMUM VOLTAGE 3* / 1000• Vdc • = voltage version REVERSE PANEL NUT MINIMUM MIN/MAX. THICKNESS 1.5-13.0 mm PANEL CUTOUT TORQUE 0.65 Nm MOUNTING CENTRES x,y=14.5 mm MOUNTING 8.1 mm OPTIONAL FLYING LEAD TERMINATIONS ORDER SUFFIX 15 15 19 19 CODE SUPPLY WIRE WIRE NO/DIAMETER CONDUCTORS OF DIAMETER INSULATION OVER COMMENTS VOLTAGE COLOUR LENGTH DC Products AC Products DC Products AC Products Red-anode / Black-cathode Brown-live / Blue-neutral Red-anode / Black-cathode Brown-live / Blue-neutral 150mm 150mm 1000mm 1000mm Customised available 19/0.15mm 1.2mm lengths website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 MARL INTERNATIONAL LTD 2008 : DS 034/06 Issue 4 SAMPLES AVAILABLE Page 2 of 3 DERATING INFORMATION 501 & 521 532, 930 & 997 ALSO AVAILABLE Part numbers also available in the 507 Series: PART NO. COLOUR VOLTAGE DC (Vdc) Vopr 507-501-04 507-501-04-15 507-501-20 507-501-22 507-501-22-15 507-501-24 507-501-25 507-501-54 507-501-56 507-501-70 507-501-72 507-501-75 507-501-75-15 507-501-77 507-501-86 507-502-04 507-502-22 507-502-23-09 507-503-04 507-503-04-15 507-503-20 507-503-21 507-503-22 507-503-23 507-503-24 507-503-75 507-503-75-15 507-506-23-09 UNITS Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Red Orange 20mA 20mA 5/6 Vdc 24 Vdc 24 Vdc 48 Vdc 110 Vdc 32 Vdc 72 Vdc 5/6 Vac 24 Vac 110 Vac 110 Vac 125 Vac 115 Vac 20mA 24 Vdc 28 Vdc 20mA 20mA 5/6 Vdc 5/6 Vdc 24 Vdc 24 Vdc 48 Vdc 110 Vac 110 Vac 28 Vdc 507-506-25 507-509-04 507-509-21 507-509-22 507-509-23 507-509-75 507-509-86 507-512-04 507-512-04-15 507-512-20 507-512-21 507-512-22 507-512-23-09 507-512-24 507-512-50 507-512-72 507-512-75 507-512-86 507-521-04 507-521-22 507-521-22-15 507-521-23-09 507-521-24 507-521-50 507-521-75-15 507-532-04 507-532-04-15 507-532-22 UNITS Orange Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green Green Green Green Green Green Green Green Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green PART NO. COLOUR VOLTAGE DC (Vdc) Vopr 110 Vdc 20mA 12 Vdc 24 Vdc 28 Vdc 110 Vac 115 Vac 20mA 20mA 5/6 Vdc 12 Vdc 24 Vdc 28 Vdc 48 Vdc 125 Vdc 24 Vac 110 Vac 115 Vac 20mA 24 Vdc 24 Vdc 28 Vdc 48 Vdc 125 Vdc 110 Vac 20mA 20mA 24 Vdc 507-532-22-15 507-532-24 507-532-25 507-532-50 507-532-54 507-532-75-15 507-532-75-19 507-532-86 507-930-04 507-930-04-15 507-930-22 507-930-22-09 507-930-22-15 507-930-23-15 507-930-25-15 507-930-25-50 507-930-54 507-997-04 507-997-24 507-997-56 507-997-72 507-997-75 UNITS Green Green Green Green Green Green Green Green Blue Blue Blue Blue Blue Blue Blue Blue Blue White White White White White PART NO. COLOUR VOLTAGE DC (Vdc) Vopr 24 Vdc 48 Vdc 110 Vdc 125 Vdc 32 Vdc 110 Vac 110 Vac 115 Vac 20mA 20mA 24 Vdc 24 Vdc 24 Vdc 28 Vdc 110 Vdc 110 Vdc 32 Vdc 20mA 48 Vdc 72 Vdc 24 Vac 110 Vac The products listed above illustrate all of the options available to order. These products may have custom modifications that alter their operation beyond the generic information contained within this datasheet. Please contact sales for further information. website: www.marl.co.uk • email: sales@marl.co.uk • • T elephone +44 (0)1229 582430 • Fax: +44 (0)1229 585155 relating to either products or service. for products or service. The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation Marl International reserve the right to alter without notice the specification or any conditions of supply Approved Manufacturer BS EN ISO 9001:2000 MARL INTERNATIONAL LTD 2008 : DS 034/06 Issue 4 SAMPLES AVAILABLE Page 3 of 3
