B5817WS THRU B5819WS
Features
• Halogen Free Available Upon Request By Adding Suffix "-HF"
• Guard Ring Protection
• Low Forward Voltage Drop
• For Use In Low Voltage, High Frequency Inverters
• High Surge Current Capability
• Epoxy Meets UL 94 V-0 Flammability Rating
• Moisture Sensitivity Level 1
• Lead Free Finish/RoHS Compliant ("P" Suffix Designates RoHS
Compliant. See Ordering Information)
1 Amp Schottky
Barrier Rectifier
20 - 40 Volts
Maximum Ratings
• Operating Junction Temperature Range: -65°C to +125°C
• Storage Temperature Range: -65°C to +150°C
• Maximum Thermal Resistance: 500°C/W Junction to Ambient
MCC
Part Number
Device
Marking
SOD-323
Maximum
Maximum DC
Recurrent
Maximum
Blocking
Peak Reverse RMS Voltage
Voltage
Voltage
B5817WS
SJ
20V
14V
20V
B5818WS
SK
30V
21V
30V
B5819WS
SL
40V
28V
40V
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
IF(AV)
1.0A
Tc = 90°C
Peak Forward Surge
Current
IFSM
10A
8.3ms Half Sine
PD
250mW
Maximum
B5817WS
Instantaneous B5818WS
Forward
B5819WS
Voltage
VF
0.45V
0.55V
0.60V
IFM=1.0A;
TJ = 25°C (Note 1)
0.75V
0.875V
0.90V
IFM=3.0A;
TJ = 25°C (Note 1)
200µA(Max)
30µA(Typ)
VR = 20V, TA = 25°C
B5818WS
40µA(Max)
4µA(Typ)
VR = 30V, TA = 25°C
B5819WS
40µA(Max)
7µA(Typ)
VR = 40V, TA = 25°C
Typical Junction
Capacitance
IR
CJ
120pF
C
E
Cathode Mark
H
D
J
G
DIM
Power Dissipation
Reverse Leakage
Current
B5817WS
A
B
A
B
C
D
E
G
H
J
DIMENSIONS
INCHES
MM
MIN MAX MIN MAX
0.090 0.113 2.30 2.88
0.063 0.071 1.60 1.80
0.045 0.053 1.15 1.35
0.031 0.049 0.80 1.24
0.010 0.016 0.25 0.40
0.004 0.018 0.10 0.45
0.004 0.010 0.10 0.25
----- 0.006 ----- 0.15
NOTE
Suggested Solder Pad Layout
1.88mm
0.69mm
Measured at
1.0MHz , VR=4.0V
0.56mm
Notes: 1. Pulse Test: Pulse Width 300usec, Duty Cycle 2%
Rev.3-1-01012019
1/3
MCCSEMI.COM
B5817WS THRU B5819WS
Curve Characteristics
12
1.0
10
Peak Forward Surge Current (A)
Average Forward Current (A)
Fig. 1 - Forward Current Derating Curve
1.2
0.8
0.6
0.4
0.2
Resistive or Inductive Load
0.0
0
25
50
100
75
6
4
2
0
125
10
1
100
Case Temperature (°C)
Number of Cycles at 60 Hz
Fig. 3 - Typical Instantaneous Forward Characteristics
Fig. 4 - Typical Instantaneous Forward Characteristics
5
TJ=125°C
2
Instantaneous Forward Current (A)
Instantaneous Forward Current (A)
8
8.3 ms Single Half Sin
5
1
0.5
0.2
0.1
TJ=75°C
0.05
TJ=25°C
0.02
0.01
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
TJ=125°C
0.5
0.2
TJ=75°C
0.1
0.05
TJ=25°C
B5819WS
0.1
0.2
0.3
0.4
0.5
0.6
0.7
Instantaneous Forward Voltage (V)
Instantaneous Forward Voltage (V)
Fig. 5 - Typical Reverse Leakage Characteristics
Fig. 6 - Typical Reverse Leakage Characteristics
0.8
Instantaneous Reverse Leakage Current (μA)
10000
TJ=125°C
TJ=75°C
100
10
TJ=25°C
B5817WS
40
60
80
1000
100
TJ=125°C
100
TJ=75°C
10
TJ=25°C
1
20
Percent of Rated Peak Reverse Voltage (%)
Rev.3-1-01012019
1
0.01
0.0
0.8
1000
1
20
2
0.02
B5817WS
10000
Instantaneous Reverse Leakage Current (μA)
Fig. 2 - Maximum Non-Repetitive Peak Forward Surge
Current
40
60
B5819WS
80
100
Percent of Rated Peak Reverse Voltage (%)
2/3
MCCSEMI.COM
B5817WS THRU B5819WS
Ordering Information
Device
Packing
Part Number-TP
Tape&Reel: 3Kpcs/Reel
Note : Adding "-HF" Suffix For Halogen Free, eg. Part Number-TP-HF
