MCC
Micro Commercial Components
TM
omponents 20736 Marilla Street Chatsworth !"# $
% !"#
BAS316
Features
•
• • • • • • •
Lead Free Finish/RoHS Compliant ("P" Suffix designates RoHS Compliant. See ordering information) Epoxy meets UL 94 V-0 flammability rating Moisture Sensitivity Level 1 Surface Mount Package Ideally Suited for Automatic Insertion High switching speed: max. 4ns Continuous reverse voltage: max. 100V R epetitive peak reverse voltage: max. 100V Repetitive peak forward current: max. 500mA
High Speed Switching Diode 400mW
SOD-323
A B
Mechanical Data • Marking: A6 .
• Polarity: Indicated by Cathode Band
Parameter DC Reverse Voltage Forward Current Total Device Dissipation Junction and Storage temperature Symbol VR IF PD T j,Pstg Limits 100 250 400 -65~+150 Unit V mA mW ℃
H
C
E
Maximum Ratings @ 25°C Unless Otherwise Specified
D
G
J
Non-repetitive peak forward current t=1us t=1ms t=1s
IFSM
4 1 0.5
DIM
A
A B C D E G H J
Electrical Characteristics @ 25°C Unless Otherwise Specified
Parameter Reverse breakdown voltage Symbol Test Conditons MIN VBR IR=100uA IF=1mA Forward voltage VF IF=10mA IF=50mA IF=150mA Reverse leakage current Reverse recovery time Diode capacitance IR Trr CD VR=25V VR=75V IF=IR=10mAdc, RL=100 VR=0V,f =1MHz 100 … … … … … … … … MAX UNIT … 715 855 1000 1250 0.03 1 uA mV V
DIMENSIONS INCHES MM MIN MAX MIN MAX .090 .107 2.30 2.70 .063 .071 1.60 1.80 .045 .053 1.15 1.35 .031 .045 0.80 1.15 .010 .016 0.25 0.40 .004 .018 0.10 0.45 .004 .010 0.10 0.25 ----.006 ----0.15
SUGGESTED SOLDER PAD LAYOUT
0.074"
NOTE
0.027”
4 1.5
ns pF
0.022”
Revision: B
www.mccsemi.com
1 of 4
2011/04/20
MCC
TM
BAS316
500 IF (mA) 400 300
Micro Commercial Components
handbook, halfpage
handbook, halfpage
IF (mA)
(1) (2) (3)
200 300
200 100 100
0 0 50 100 150 Ts (oC) 200
0
0
1
(1) Tj = 150 °C; typical values. (2) Tj = 25 °C; typical values. (3) Tj = 25 °C; maximum values.
VF (V)
2
Fig.1
Maximum permissible continuous forward current as a function of soldering point temperature.
Fig.2
Forward current as a function of forward voltage.
102 handbook, full pagewidth IFSM (A)
10
1
10−1 1 10
102
103
tp (µs)
104
Based on square wave currents. Tj = 25 °C prior to surge.
Fig.3 Maximum permissible non-repetitive peak forward current as a function of pulse duration.
www.mccsemi.com
Revision: B
2 of 4
2011/04/20
MCC
TM
BAS316
Micro Commercial Components
105 IR (nA) 10
4
handbook, halfpage
0.8
Cd (pF) V R = 75 V 0.6
103
max
75 V
0.4
10
2
25 V 0.2 typ typ
10
0 100 T j ( o C) 200 0 4 8 12 VR (V) 16
0
f = 1 MHz; Tj = 25 °C.
Fig.4
Reverse current as a function of junction temperature.
Fig.5
Diode capacitance as a function of reverse voltage; typical values.
www.mccsemi.com
Revision: B
3 of 4
2011/04/20
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Packing
Tape&Reel: 3Kpcs/Reel
***IMPORTANT NOTICE* **
Micro Comme rcial Components Corp. reserves the right to make changes without further notice to any product herein to make corrections, modifications , enhancements , improvements , or other changes . Micro Comme rcial Components Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all risks of such use and will agree to hold Micro Commercial Co mponents Corp . and all the companies whose products are represented on our website, harmless against all damages. ***LIFE SUPPORT*** MCC's products are not authorized for use as critical components in life support devices or systems without the express written approval of Micro Commercial Components Corporation. ***CUSTOMER AWARENESS*** Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages customers to purchase MCC parts either directly from MCC or from A uthorized MCC Distributors who are listed by country on our web page cited below. Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine parts, have full traceability, meet MCC' s quality standards for handling and storage. MCC will not pro vide any warranty coverage or o ther assistance for parts bought from Unau thorized Source s. MCC is committed to combat this global problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized distributors.
www.mccsemi.com
Revision: B
4 of 4
2011/04/20
