BAV20

MCC Micro Commercial Components TM
  omponents 20736 Marilla Street Chatsworth    !"# $ %    !"# BAV19 THRU BAV21 500mW Small Signal Diodes 120 to 250 Volts Features • • • • Silicon Epitaxial Planar Diodes For General Purpose This diode is also available in other case. Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates Compliant. See ordering information) Mechanical Data • • • • Case: DO-35 Glass Case W eight: approx. 0.13g Marking : Cathode band and type number Moisture Sensitivity Level 1 DO-35 GLASS Maximum Ratings Symbol VR BAV19 BAV20 BAV21 Repetitive Peak Reverse Voltage BAV19 BAV20 BAV21 Forward DC Current at Tamb=25OC(1) Rectified Current (Average) Half Wave Rectification with Resist. Load at Tamb=25OC(1) Repetitive Peak Forward Current at f>50Hz, Tamb=25OC(1) Surge Forward Current at t
