SK3200

MCC Micro Commercial Components TM
  omponents 20736 Marilla Street Chatsworth    !"# $ %    !"# SK3200 Features • • • • • Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates RoHS Compliant. See ordering information) Case Material:Molded Plastic. UL Flammability Classification Rating 94V-0 and MSL Rating 1 For Surface Mount Applications Easy Pick And Place High Temp Soldering: 260 °C for 10 Seconds At Terminals 3 Amp Schottky Rectifier 200 Volts DO-214AB (SMC) (LEAD FRAME) A Maximum Ratings • • • Operating Temperature: -55 °C to +150°C Storage Temperature: -55°C to +150°C Maximum Thermal Resistance; 11 °C/W Junction To Lead MCC Catalog Number SK3200 Device Marking Maximum Recurrent Peak Reverse Voltage 200V Maximum RMS Voltage 140V Maximum DC Blocking Voltage 200V B C SK3200 F H D G E Electrical Characteristics @ 25°C Unless Otherwise Specified Average Forward Current Peak Forward Surge Current Maximum Instantaneous Forward Voltage Maximum DC Reverse Current At Rated DC Blocking Voltage IF(AV) IFSM 3.0A 100A TL = 70°C 8.3ms, half sine IFM = 3.0A; TJ = 25°C DIM A B C D E F G H DIMENSIONS INCHES MIN .260 .220 .006 .030 .305 .079 .108 .002 MM MIN 6.60 5.59 0.15 0.76 7.75 2.00 2.75 0.050 VF .86V MAX .280 .245 .012 .060 .320 .103 .128 .008 MAX 7.11 6.22 0.31 1 ..52 8.13 2.62 3.25 0.203 NOTE IR 0.5mA TJ = 25°C SUGGESTED SOLDER PAD LAYOUT 0.185 Notes: 1. High Temperature Solder Exemption Applied, see EU Directive Annex Notes 7. 0.121” 0.060” www.mccsemi.com Revision: 1 1 of 2 2010/01/29 MCC Micro Commercial Components TM Ordering Information Device (Part Number)-TP Packing Tape&Reel;3Kpcs/Reel ***IMPORTANT NOTICE*** Micro Commercial Components Corp . reserve the right to make changes without further notice to any product herein to make corrections, modifications , enhancements , improvements , or other changes . Micro Commercial Components Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all risks of such use and will agree to hold Micro Commercial Components Corp . and all the companies whose products are represented on our website, harmless against all damages. ***APPLICATIONS DISCLAIMER*** Products offer by Micro Commercial Components Corp . are not intended for use in Medical, Aerospace or Military Applications. Revision: 1 www.mccsemi.com 2 of 2 2010/01/29 2
