SOT-363

MCC Micro Commercial Components TM Micro Commercial Components 20736 Marilla Street Chatsworth CA 91311 Phone: (818) 701-4933 Fax: (818) 701-4939 ESD5V0K5 Features • • • • • • • For sensitive ESD protection Excellent clamping capability Low leakage ESD rating of class 3(>16KV)per Human Body Mode For space saving application Fast response ,response time less than 1ns. Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 and MSL rating 1 5 Volts ESD Protection Device Maximum Ratings • • Operating Junction &StorageTemperature: -55°C to +150°C Maximum Thermal Resistance; 833°C/W Junction To Ambient G SOT-363 B C Parameter IEC61000-4-2(ESD) Symbol Air Contact Pd Ppk ESD Voltage per human body mode Power Dissipation(Note 1) Peak Power Dissipation@8/20us Limits ±15 ±15 16 150 100 unit KV KV mw W K J D L A H M 1. Only 1 diode under power. For all 5 diodes under power, PD will be 20%. Mounted on FR--4 board with min pad. PinConfiguration DIMENSIONS INCHES DIM A B C D G H J K L M MIN .006 .045 .085 .026 .047 .071 --.035 .010 .003 .055 .087 .004 .043 .018 .006 MAX .014 .053 .096 MM MIN MAX 0.15 0.35 1.15 1.35 2.15 2.45 0.65Nominal 1.20 1.40 1.80 2.20 --0.10 0.90 1.10 0.26 0.46 0.08 0. 15 NOTE Revision: 3 www.mccsemi.com 1 of 3 2008/12/31 MCC Micro Commercial Components TM ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted, VF = 0.9 V Max. @ IF = 10mA for all types) IR (μA) Device Device* Marking Max ESD5V0K5 Max Min Max mA VRWM (V) @ VRWM @ IT IPP=1A Max IPP=5A Max Max Max VC (V) VBR (V) IT @Max @Max C (pF) VC (V) IPP(A) 22 5.0 5 6.0 7.2 1.0 9.5 12.5 8 130 www.mccsemi.com Revision: 3 2 of 3 2008/12/31 MCC TM Micro Commercial Components Ordering Information Device (Part Number)-TP Packing Tape&Reel;3Kpcs/Reel ***IMPORTANT NOTICE*** Micro Commercial Components Corp . reserves the right to make changes without further notice to any product herein to make corrections, modifications , enhancements , improvements , or other changes . Micro Commercial Components Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all risks of such use and will agree to hold Micro Commercial Components Corp . and all the companies whose products are represented on our website, harmless against all damages. ***APPLICATIONS DISCLAIMER*** Products offer by Micro Commercial Components Corp . are not intended for use in Medical, Aerospace or Military Applications. www.mccsemi.com Revision: 3 3 of 3 2008/12/31
