SOT-563

MCC Micro Commercial Components TM Micro Commercial Components 20736 Marilla Street Chatsworth CA 91311 Phone: (818) 701-4933 Fax: (818) 701-4939 ESD5V0M5 Features • • • • • • • For sensitive ESD protection Excellent clamping capability Low leakage ESD rating of class 3(>16KV)per Human Body Mode For space saving application Fast response ,response time less than 1ns. Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 and MSL rating 1 5 Volts ESD Protection Device SOT-563 A BC Maximum Ratings • • Operating Junction &StorageTemperature: -55°C to +150°C Maximum Thermal Resistance; 833°C/W Junction To Ambient Symbol Air Contact Pd Ppk Limits ±15 ±15 16 150 100 unit KV KV mw W Parameter IEC61000-4-2(ESD) D G ESD Voltage per human body mode Power Dissipation(Note 1) Peak Power Dissipation@8/20us K H M 1. Only 1 diode under power. For all 5 diodes under power, PD will be 20%. Mounted on FR--4 board with min pad. L DIMENSIONS INCHES DIM A B C D G H K L M MIN .006 .043 .061 .020 .035 .059 .022 .004 .004 .043 .067 .023 .011 .007 0.90 1.50 0.56 0.10 0.10 MAX .011 .049 .067 MIN 0.15 1.10 1.55 0.50 1.10 1.70 0.60 0.30 0.18 MM MAX 0.30 1.25 1.70 NOTE PinConfiguration Revision: 2 www.mccsemi.com 1 of 3 2008/02/10 MCC Micro Commercial Components TM ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted, VF = 0.9 V Max. @ IF = 10mA for all types) IR (μA) Device Device* Marking Max ESD5V0M5 Max Min Max mA VRWM (V) @ VRWM @ IT IPP=1A Max IPP=5A Max Max Max VC (V) VBR (V) IT @Max @Max C (pF) VC (V) IPP(A) 52 5.0 5 6.0 7.2 1.0 10.5 13.5 8 120 Revision: 2 www.mccsemi.com 2 of 3 2008/02/10 MCC TM Micro Commercial Components Ordering Information Device (Part Number)-TP Packing Tape&Reel;3Kpcs/Reel ***IMPORTANT NOTICE*** Micro Commercial Components Corp . reserves the right to make changes without further notice to any product herein to make corrections, modifications , enhancements , improvements , or other changes . Micro Commercial Components Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all risks of such use and will agree to hold Micro Commercial Components Corp . and all the companies whose products are represented on our website, harmless against all damages. ***APPLICATIONS DISCLAIMER*** Products offer by Micro Commercial Components Corp . are not intended for use in Medical, Aerospace or Military Applications. Revision: 2 www.mccsemi.com 3 of 3 2008/02/10
