HLP-80H_12

80W Single Output Switching Power Supply Features : HLP-80H series Universal AC input / Full range (up to 305VAC) Built-in active PFC function Protections: Short circuit / Over current / Over voltage / Over temperature Cooling by free air convection Output constant current level adjustable Class 2 power unit Three in one dimming function (1~10Vdc or PWM signal or resistance) Suitable for built in LED lighting system Suitable for dry / damp locations 100% full load burn-in test 3 years warranty M M SELV ( for 48V,54V only) ( except for 48V,54V ) SPECIFICATION MODEL DC VOLTAGE RATED CURRENT RATED POWER VOLTAGE ADJ. RANGE CURRENT ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD UP TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT(Typ.) LEAKAGE CURRENT OVER CURRENT SHORT CIRCUIT Note.4 HLP-80H-12 HLP-80H-15 HLP-80H-20 HLP-80H-24 HLP-80H-30 HLP-80H-36 HLP-80H-42 HLP-80H-48 HLP-80H-54 12V 5A 60W 15V 9 ~ 15V 5A 75W 150mVp-p 20V 12 ~ 20V 4A 80W 150mVp-p 17 ~ 22V 3.2 ~ 4A 1.0% 0.5% 24V 14.4 ~ 24V 3.4A 81.6W 150mVp-p 22 ~ 27V 2.72 ~ 3.4A 1.0% 0.5% 0.5% 30V 18 ~ 30V 2.7A 81W 200mVp-p 27 ~ 33V 2.16 ~ 2.7A 1.0% 0.5% 0.5% 36V 21.6 ~ 36V 2.3A 82.8W 200mVp-p 33 ~ 40V 1.84 ~ 2.3A 1.0% 0.5% 0.5% 42V 25.2 ~ 42V 1.95A 81.9W 200mVp-p 38 ~ 46V 48V 28.8 ~ 48V 1.7A 81.6W 200mVp-p 43 ~ 53V 54V 32.4 ~ 54V 1.5A 81W 200mVp-p 49 ~ 58V 1.2 ~ 1.5A 1.0% 0.5% 0.5% CONSTANT CURRENT REGION Note.4 7.2 ~12V RIPPLE & NOISE (max.) Note.2 150mVp-p OUTPUT 10.8 ~ 13.5V 13.5 ~ 17V 4 ~ 5A 2.5% 0.5% 4 ~ 5A 2.0% 0.5% Can be adjusted by internal potentiometer or through output connector 1.56 ~ 1.95A 1.36 ~ 1.7A 1.0% 1.0% 0.5% 0.5% 0.5% 0.5% 1.5% 1.0% 2.0% Note.6 2000ms, 200ms / 115VAC at full load 16ms at full load Note.5 90 ~ 305VAC 1000ms, 200ms / 230VAC at full load 230VAC /115VAC 127 ~ 431VDC 47 ~ 63Hz PF>0.96/115VAC, PF>0.96/230VAC, PF>0.94/277VAC at full load (Please refer to "Power Factor Characteristic" curve) 89.5% 88.5% 0.85A / 115VAC 0.425A / 230VAC COLD START 70A/230VAC
