LPV-35_12

35W Single Output Switching Power Supply Features : L P V- 3 5 series Constant voltage design Universal AC input / Full range Withstand 300VAC surge input for 5 seconds Protections: Short circuit / Overload / Over voltage Cooling by free air convection Fully encapsulated with IP67 level (Note.9) Fully isolated plastic case Class power unit, no FG Class 2 power unit Pass LPS Suitable for LED lighting and moving sign applications (Note.8) 100% full load burn-in test Low cost, high reliability 2 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD UP TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT(max.) LEAKAGE CURRENT OVERLOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS SAFETY & EMC WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION EMC IMMUNITY MTBF OTHERS DIMENSION PACKING NOTE LPS IP67 LPV-35-5 5V 5A 0 ~ 6A (Note.7) 30W 6.0% 1.0% 4.0% Note.6 500ms, 20ms / 230VAC LPV-35-12 12V 3A 0 ~ 3A 36W 120mVp-p 5.0% 2.0% LPV-35-15 15V 2.4A 0 ~ 2.4A 36W 120mVp-p LPV-35-24 24V 1.5A 0 ~ 1.5A 36W 150mVp-p LPV-35-36 36V 1A 0 ~ 1A 36W 150mVp-p RIPPLE & NOISE (max.) Note.2 80mVp-p 500ms, 20ms / 115VAC at full load 50ms/230VAC Note.4 90 ~ 264VAC 16ms/115VAC at full load 127 ~ 370VDC 84% 60A/230VAC 84% 85% 85% 47 ~ 63Hz 77% 1.1A/115VAC 0.7A/230VAC COLD START 30A/115VAC 0.25mA / 240VAC 110 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed 5.75 ~ 6.75V 13.8 ~ 16.2V 17.25 ~ 20.25V 27.6 ~ 32.4V Protection type : Shut down o/p voltage, re-power on to recover -30 ~ +75 -40 ~ +80 (Refer to "Derating Curve") , 10 ~ 95% RH 20 ~ 90% RH non-condensing 0.03%/ (0 ~ 50 ) 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes UL1310, CAN/CSA C22.2 No. 223-M91, IP67 approved ; design refer to TUV EN60950-1 I/P-O/P:3KVAC I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH Compliance to EN55022 (CISPR22) Class B, EN61000-3-2 Class A, EN61000-3-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A 743.5Khrs min. MIL-HDBK-217F (25 ) 148*40*30mm (L*W*H) 0.34Kg; 40pcs/14.6Kg/0.63CUFT 41.4 ~ 48.6V 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. Derating may be needed under low input voltage. Please check the static characteristics for more details. 5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again. 6. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time. 7. LPV-35-5 can provide 6A of output current continuously. Based on the requirement of UL1310 class 2, the output current is only certified up to 5A for the test report of LPV-35-5. 8. The unit might not be suitable for lighting applications in EU countries. Please check with your local authorities for the possible use of the unit. 9. Suitable for indoor use or outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minute. File Name:LPV-35-SPEC 2012-03-20 35W Single Output Switching Power Supply Mechanical Specification L P V- 3 5 Case No.975A series Unit:mm 600 30 UL1015 18AWG 148 3.5 600 30 40 AC/N(Blue) AC/L(Brown) T case 3.5 3.5 T case: Max. Case Temperature. 30 Recommend Mounting Direction Block Diagram fosc : 65KHz I/P EMI FILTER & RECTIFIERS POWER SWITCHING RECTIFIERS & FILTER 18 3.6 3.6 26.5 3.5 UL1007 16AWG +V(Red) -V(Black) +V -V O.L.P. PWM CONTROL DETECTION CIRCUIT O.V.P. Derating Curve Static Characteristics 100 100 24~36V 90 80 80 60 5~15V 70 LOAD (%) 40 LOAD (%) 0 15 30 40 50 55 60 65 70 80 (HORIZONTAL) 60 50 40 20 -30 90 100 125 135 145 155 165 175 180 200 230 264 AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (V) 60Hz File Name:LPV-35-SPEC 2012-03-20
