MS-150

450W/650W/1000W Modular Power Features : MP Various output configuration is selectable Built in active PFC, PF>0.95 Universal AC input/ full range Remote Control on every individual output module series ZVT technology to reduce power dissipation and improve efficiency Remote Sense on every individual output module(MS-75,150,300) Built in parallel function(MS-300) Protections: Short circuit / Overload / Over voltage for all output modules Additional 12V/0.1A auxiliary output for remote control Cooling by built-in DC fan with fan alarm function 3 years warranty Output Configuration Guide MP SLOT1 SLOT2 SLOT3 SLOT4 SLOT5 SLOT6 SLOT7 450/650/1K0(450W/650W/1000W) Modular Power with PFC 450W/650W(5SLOT) Parallel or option code (See Table 1.) 1000W(7SLOT) - Single output(MS-150) 1 SLOT (150W max.) Voltage code A B C D E F G H I J K Voltage 2V 3.3V 5V 7.5V 12V 15V 18V 24V 27V 33V 48V Single output(MS-300) 2 SLOT (300W max.) Voltage code 2A 2B 2C 2D 2E 2F 2G 2H 2I 2J 2K Voltage 2V 3.3V 5V 7.5V 12V 15V 18V 24V 27V 33V 48V Single output(MS-75) 1 SLOT (75W max.) Voltage code L M N O P Q Voltage 3.3V 5V 12V 15V 24V 48V Dual output(MD-100) 1 SLOT (100W max.) Voltage code R S T U V W X Voltage 5V 5V 5V 12V 5V 15V 24V 5V 24V 12V 12V 12V 15V 15V Example: MP1K0- A SLOT1 O/P:2V@25A 2 E # S 2 K SLOT2,3 O/P:12V@25A SLOT4 Blank Slot SLOT5 O/P:5V@10A 12V@4.2A SLOT6,7 O/P:48V@6.3A SPECIFICATION MODEL VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR INPUT EFFICIENCY AC CURRENT INRUSH CURRENT LEAKAGE CURRENT OUTPUT PROTECTION TOTAL OUTPUT POWER OVER TEMPERATURE FAN ALARM FUNCTION REMOTE CONTROL AUXILIARY POWER(AUX) WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE SAFETY & EMC (Note 5) PFC-450 85 ~ 264VAC 47 ~ 63Hz PF>0.95/230VAC Note.1 83% typ. PFC-650 120 ~370VDC PF>0.98/115VAC at full load 84% typ. 3.2A/230VAC 9A/115VAC 30A/115VAC 4.5A/230VAC 50A/230VAC PFC-1000 84% typ. 13.5A/115VAC 20A/115VAC 1000W max. 6.7A/230VAC 40A/230VAC 6.3A/115VAC 25A/115VAC 40A/230VAC
