PB-230_11

厂商：
MEANWELL(明纬)
封装：
描述：
PB-230_11 - 230W Single Output Battery Charger - Mean Well Enterprises Co., Ltd.

数据手册：

下载PB-230_11.pdf

立即购买

详情介绍
数据手册
价格&库存

PB-230_11 数据手册

230W Single Output Battery Charger Features : 3 stage charging characteristic Universal AC input / Full range PB-230 Built-in active PFC function, PF>0.95 series Protection: Short circuit / Overload / Over voltage / Over temperature Built-in cooling Fan ON-OFF control Built-in remote ON-OFF control 2 color LED loading indicator Low cost, high reliability 2 years warranty ( for PB-230-xxAD1 only) TUV Rheinland Product Safety geprUfre Sicherheit ORDER NO. PB-230-xx (standard model) PB-230-xxAD1 (optional model) PB-230-xx MODEL BOOST CHARGE VOLTAGE FLOAT CHARGE VOLTAGE OUTPUT RECOMMENDED BATTERY CAPACITY(AMP HOURS)(Note 5) BATTERY TYPE OUTPUT CURRENT VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVERLOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE OUTPUT CONNECTOR 4pin power din Anderson connector =Blank, AD1 PB-230-12 14.4V 13.6V 50 ~ 160Ah Open & Sealed Lead Acid 16A 90 ~ 264VAC 47 ~ 63Hz PF>0.95/230VAC 81.5% 3A/115VAC 1.5A/230VAC COLD START 50A 0.98/115VAC at full load 85.5% 127 ~ 370VDC 8A PB-230-24 28.8V 27.2V 24 ~ 80Ah SAFETY TUV / CE UL xx=12,24,48 ; SPECIFICATION PB-230-48 57.6V 54.4V 12 ~ 40Ah 4A 86% 90 ~ 110% rated output current Protection type : Constant current limiting, recovers automatically after fault condition is removed 16 ~ 18V 31 ~ 35V Protection type : Shut down o/p voltage, re-power on to recover Protection type : Automatically derate charge current until zero Short: Stop Charging 45 Fan OFF (Typ.) 59 ~ 64V REMOTE CONTROL (CN105) Open: Normal work FUNCTION FAN CONTROL RTH3 50 Fan ON, By NTC TEMPERATURE SENSE WORKING TEMP. -20 ~ +50 (Refer to "Derating Curve") 20 ~ 90% RH non-condensing WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY -40 ~ +85 , 10 ~ 95% RH TEMP. COEFFICIENT 0.03%/ (0 ~ 50 VIBRATION 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes UL1012(for PB-230-xxAD1 only), TUV EN60950-1 approved SAFETY STANDARDS SAFETY & WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC (Note 4) EMC EMISSION EMC IMMUNITY OTHERS MTBF DIMENSION PACKING PLUG CABLE I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A 244.5Khrs min. MIL-HDBK-217F (25 ) 190*96*49mm(L*W*H) 1.21Kg; 12pcs/15.5Kg/1.29CUFT See page 2 ; Other type available by customer requested See page 2 ; Other type available by customer requested CONNECTOR NOTE 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. 5. This is Mean Well's suggested range. Please consult your battery manufacturer for their suggestions about maximum charging current limitation. File Name:PB-230-SPEC 2011-08-18 230W Single Output Battery Charger Mechanical Specification 115cm 5cm 3 4 PB-230 Case No.PB-230A 2 1 series Unit:mm AD1 (optional) CN105 12 35 2mm 96 49 Plug Assignment DC output connector (standard) UNICABLE 89M103-4P or equivalent 3 4 2 1 Block Diagram FAN ON/OFF CONTROL EMI FILTER & RECTIFIERS PFC CIRCUIT POWER SWITCHING RECTIFIERS & FILTER DETECTION CIRCUIT O.T.P. O.V.P. REMOTE CONTROL FG O.L.P. Charging Curve FUSE Air flow direction Remote Control (CN105) : JST B2B-XH or equivalent Pin No. 1 2 190 Assignment RCRC+ Mating Housing JST XHP or equivalent Terminal JST SXH-001T-P0.6 or equivalent DC output connector (optional) AD1 [ housing: Anderson 1327FP(red), 1327G6FP(black) contacts: Anderson 261G2 (45A) or equivalent ] Red(+V) Black(-V) PIN NO. OUTPUT 1,2 3,4 +V -V FAN fosc : 90KHz I/P +V -V PWM & PFC CONTROL Derating Curve Start V boost V FLT 100 90 80 Charge Voltage 100% 70 LOAD (%) Charge Current Constant Current Constant Voltage stage 1 stage 2 stage 3 10% 60 40 30 Color of LED Red Green -20 10 20 30 40 45 50 60 70 (HORIZONTAL) AMBIENT TEMPERATURE ( ) State V boost V FLT PB-230-12 14.4V 13.6V PB-230-24 28.8V 27.2V PB-230-48 57.6V 54.4V File Name:PB-230-SPEC 2011-08-18

下载 PDF

PB-230_11

### 物料型号 - 标准型号：PB-230-xx，其中xx代表输出电压，例如PB-230-12、PB-230-24、PB-230-48。 - 可选型号：PB-230-xxAD1，带有Anderson连接器的型号。

### 器件简介 PB-230系列是一款230W单输出电池充电器，具备3阶段充电特性、全范围AC输入、内置主动PFC功能（功率因数PF>0.95），并提供短路、过载、过电压、过温度保护。

### 引脚分配 - REMOTE CONTROL (CN105)：JST B2B-XH或等效，有两个引脚RC-和RC+。 - DC输出连接器（标准）：1,2为+V，3,4为-V。 - DC输出连接器（可选）：AD1外壳使用Anderson 1327FP（红色）、1327G6FP（黑色），接触件使用Anderson 261G2（45A）或等效，红色为+V，黑色为-V。

### 参数特性 - 输出电压：BOOST CHARGE VOLTAGE为14.4V，FLOAT CHARGE VOLTAGE分别为13.6V、27.2V、54.4V。 - 推荐电池容量：50~160Ah、24~80Ah、12~40Ah。 - 输出电流：16A、8A、4A。 - 输入电压范围：90~264VAC，127~370VDC。 - 频率范围：47~63Hz。 - 功率因数（典型值）：81.5%、85.5%、86%。 - 效率（典型值）：与功率因数相同。

### 功能详解 - 远程控制：CN105，开路时正常工作，短路时停止充电。 - 风扇控制：RTH3≥50°C时风扇开启，45°C时关闭。 - 温度感应：环境工作温度为-20~+50°C。

### 应用信息 PB-230系列适用于铅酸电池的充电，具有高可靠性和低成本，提供2年保修。

### 封装信息 - 尺寸：1909649mm(LWH)。 - 包装：1.21Kg；12pcs/15.5Kg/1.29CUFT。
