PLP-45

厂商：
MEANWELL(明纬)
封装：
描述：
PLP-45 - 45W Single Output LED Power Supply - Mean Well Enterprises Co., Ltd.

数据手册：

下载PLP-45.pdf

立即购买

详情介绍
数据手册
价格&库存

PLP-45 数据手册

45W Single Output LED Power Supply Features : Universal AC input / Full range PLP-45 series Protections: Short circuit / Over current / Over voltage Built-in active PFC function Cooling by free air convection Output current level adjustable 100% full load burn-in test High reliability Suitable for built-in applications of LED lighting 2 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT CURRENT ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP TIME VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (max.) LEAKAGE CURRENT OVER CURRENT PROTECTION SHORT CIRCUIT OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS SAFETY & EMC WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION EMC IMMUNITY MTBF OTHERS DIMENSION PACKING NOTE Note.5 ( for 48V only) ( except for 48V ) PLP-45-12 12V 3.8A 0 ~ 3.8A 45.6W 2.85 ~ 3.8A 10% 3.0% 5.0% CONSTANT CURRENT OPERATION VOLTAGE Note.5 9 ~ 12V PLP-45-24 24V 18 ~ 24V 1.9A 0 ~ 1.9A 45.6W 3.8Vp-p 1.425 ~ 1.9A PLP-45-48 48V 36 ~ 48V 0.95A 0 ~ 0.95A 45.6W 4.8Vp-p 0.715 ~ 0.95A RIPPLE & NOISE (max.) Note.2 4.2Vp-p 1000ms / 230VAC 2000ms / 115VAC at full load Note.4 90 ~ 264VAC 127 ~ 370VDC 47 ~ 63Hz PF 0.9 at 75 ~ 100% load, 115VAC / 230VAC 86% 0.6A/115VAC 42A/230VAC 100 ~ 110% Protection type : Constant current limiting, recovers automatically after fault condition is removed Protection type : Hiccup mode, recovers automatically after fault condition is removed 15 ~ 18V -30 ~ +70 (Refer to "Derating Curve") 28 ~ 35V 57 ~ 63V Protection type : Shut down o/p voltage, re-power on to recover 20 ~ 95% RH non-condensing -40 ~ +80 , 10 ~ 95% RH 0.03%/ (0 ~ 50 ) 10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes UL8750, CAN/CSA C22.2 No. 250.0-08(except for 48V),TUV EN61347-1, EN61347-2-13 approved ; design refer to UL60950-1 I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Compliance to EN55015, EN61000-3-2 Class C( 75% load); EN61000-3-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN61547, light industry level, criteria A 586.5Khrs min. MIL-HDBK-217F (25 ) 101.6*50.8*29.6mm (L*W*H) 0.16Kg; 96pcs/16.4Kg/0.89CUFT 0.3A/230VAC 89% 89%

下载 PDF

PLP-45

### 物料型号 - 型号包括：PLP-45-12（12V）、PLP-45-24（24V）、PLP-45-48（48V）。

### 器件简介 - 该系列是一款45W单路输出LED电源供应器，具有以下特点： - 通用交流输入/全范围 - 保护功能：短路、过流、过压 - 内置主动PFC功能 - 通过自然对流冷却 - 输出电流可调，100%满负载老化测试 - 高可靠性，适用于LED照明的内置应用 - 2年保修期

### 引脚分配 - AC输入连接器（N1）：JST B3P-VH或等效型号 - 1号引脚：AC/L - 2号引脚：无引脚 - 3号引脚：AC/N - DC输出连接器（CN2）：JST B2P-VH或等效型号 - 1号引脚：+V - 2号引脚：-V

### 参数特性 - 输出电压：12V、24V、48V - 恒流操作电压范围：9~12V、18~24V、36~48V - 额定电流：3.8A、1.9A、0.95A - 电流范围：0~3.8A、0~1.9A、0~0.95A - 额定功率：均为45.6W - 纹波与噪声：最大值分别为4.2Vp-p、3.8Vp-p、4.8Vp-p - 电流调整范围：2.85~3.8A、1.425~1.9A、0.715~0.95A - 电压容差：±10% - 线路调整率：±3.0% - 负载调整率：±5.0%，1000ms/230VAC、2000ms/115VAC在满负载下 - 输入电压范围：90~264VAC、127~370VDC - 频率范围：47~63Hz - 功率因数：在75-100%负载下，115VAC/230VAC的功率因数≥0.9 - 效率：86%、89%、89% - AC电流：115VAC下0.6A、230VAC下0.3A - 浪涌电流：230VAC下42A、240VAC下<0.75mA、100~110%

### 功能详解 - 该电源供应器具有高效率和高可靠性，适合LED照明的内置应用。具备短路、过流、过压保护功能，并内置主动PFC功能以提高功率因数。

### 应用信息 - 适用于LED照明的内置应用。

### 封装信息 - 尺寸为101.650.829.6mm（长宽高）。
