SD-15

15W Single Output DC-DC Converter Features : 2:1 wide input range SD-15 Protections:Short circuit/Over load /voltage Built-in EMI filter, low ripple noise 100% full load burn-in test Low cost High reliability 2 years warranty series SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT RIPPLE & NOISE (max.) Note.2 VOLTAGE ADJ.RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE ,HOLD UP TIME VOLTAGE RANGE INPUT EFFICIENCY(Typ.) DC CURRENT(Typ.) OVER LOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY & EMC (Note 4) SD-15A-05 5V 3A 0 ~ 3A 15W 100mVp-p 4.75~5.5VDC 2.0% 0.5% 0.5% SD-15B-05 SD-15C-05 SD-15A-12 12V 1.25A 0 ~ 1.25A 15W SD-15B-12 SD-15C-12 SD-15A-24 24V 0.625A 0 ~ 0.625A 15W 150mVp-p SD-15B-24 SD-15C-24 120mVp-p 10.8~13.2VDC 1.0% 0.3% 0.3% C:36~72VDC 76% 72% 0.45A/48VDC 79% 21.6~26.4VDC 1.0% 0.2% 0.2% 2.5s, 25ms,--- 12VDC/24VDC/48VDC at full load A: 9.2 ~18VDC B:18 ~ 36VDC 68% 76% 75% 1.9A/12VDC 0.9A/24VDC 105 ~160% rated output power 70% 77% 78% Protection type : Hiccup mode, recovers automatically after fault condition is removed 13.8~ 16.2V 5.75 ~ 6.75V Protection type : Shut off o/p voltage, clamping by zener diode -10 ~ +60 ¡ 27.6 ~ 32.4V (Refer to "Derating Curve") 20 ~ 90% RH non-condensing -20 ~ +85 , 10 ~ 95% RH 0.03%/ (0 ~ 50 ) 10 ~ 500Hz, 2G 10min./1cycle, 60min.each along X, Y, Z axes I/P-O/P:2KVAC I/P-FG:1KVAC O/P-FG:0.5KVAC I/P-O/P,I/P-FG,O/P-FG:100M Ohms / 500VDC / 25 / 70% RH Compliance to EN55022(CISPR22) Compliance to EN61000-4-2,3,4,6,8, EN55024, light industry level, criteria A 78*51*28mm (L*W*H) 0.18kg,60 PCS/11.8kg WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC EMISSION EMC IMMUNITY DIMENSION PACKING OTHERS NOTE 1. All parameters NOT specially mentioned are measured at normal input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com) File Name:SD-15-SPEC 2011-06-15 15W Single Output DC-DC Converter Mechanical Specification SD-15 Case No. 931A series Unit:mm 7.62 1 2 3 6 .6 2 4 5 +V ADJ. LED 2-M3 L=4 25.4 55 78 10.5 66.5 2.75 14 14max. Terminal Pin No. Assignment Pin No. 1 2 3 Assignment DC INPUT V+ DC INPUT VFG Pin No. 4 5 Assignment DC OUTPUT +V DC OUTPUT -V 2-M3 L=6 28 Block Diagram RECTIFIERS & FILTER RECTIFIERS & FILTER fosc : 96KHz I/P EMI FILTER POWER SWITCHING 51 +V -V OLP PWM CONTROL DETECTION CIRCUIT Derating Curve 100 80 60 LOAD (%) 40 20 -10 -10 0 10 20 30 40 50 45 60 55 (HORIZONTAL) (VERTICAL) AMBIENT TEMPERATURE ( ) File Name:SD-15-SPEC 2011-06-15
