SD-25A-5

25W Single Output DC-DC Converter Features : 2:1 wide input range SD-25 Protections: Short circuit / Overload / Over voltage 1500VAC I/O isolation Built-in EMI filter, low ripple noise 100% full load burn-in test Fixed switching frequency at 83KHz Low cost High reliability 2 years warranty series SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION VOLTAGE RANGE INPUT EFFICIENCY (Typ.) DC CURRENT OVERLOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS SAFETY & WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC (Note 4) SD-25A-5 5V 5A 0 ~ 5A 25W 4.5 ~ 5.5VDC 2.0% 0.5% 0.5% SD-25B-5 SD-25C-5 SD-25A-12 12V 2.1A 0 ~ 2.1A 25.2W 120mVp-p 11 ~ 16VDC 1.0% 0.3% 0.3% SD-25B-12 SD-25C-12 SD-25A-24 24V 1.1A 0 ~ 1.1A 26.4W 150mVp-p 23 ~ 30VDC 1.0% 0.2% 0.2% SD-25B-24 SD-25C-24 RIPPLE & NOISE (max.) Note.2 100mVp-p SETUP, RISE, HOLD UP TIME 2.5s, 50ms, ------ at full load A:9.2 ~ 18VDC 71% 3.2A/12V 72% B:19 ~ 36VDC 74% C:36 ~ 72VDC 72% 1.6A/24V 75% 78% 75% 0.8A/48V 78% 81% 105 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed 5.75 ~ 6.75V/10% load 16.8 ~ 20V/10% load Protection type : Hiccup mode, recovers automatically after fault condition is removed -10 ~ +60 -20 ~ +85 (Refer to output load derating curve) , 10 ~ 95% RH 20 ~ 90% RH non-condensing 0.03%/ (0 ~ 50 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes Design refer to LVD I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC / 70% RH 31.5 ~ 37.5V/10% load I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 EMI CONDUCTION & RADIATION Compliance to EN55022 (CISPR22) Class B EMS IMMUNITY MTBF Compliance to EN61000-4-2,3,4,6,8; ENV50204, EN55024,heavy industry level, criteria A 374.3K hrs min.(SD-25A) 365.9K hrs min.(SD-25B) 99*97*36mm (L*W*H) 0.38Kg; 45pcs/17.8Kg/0.9CUFT 377.5K Hrs min.(SD-25C) MIL-HDBK-217F (25 ) OTHERS DIMENSION PACKING NOTE 1. All parameters NOT specially mentioned are measured at 12,24,48VDC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. File Name:SD-25-SPEC 2010-07-27 50W Single Output DC-DC Converter Mechanical Specification SD-25 Case No. 905 series Unit:mm 1 9.5 2 3 51.5 5.5 8.2 2- 20.5 55 3.5 4.5 89 99 6.5 7 87 17.5 55.5 5 M 3 97 4 36 3.5 3.5 28 36 3.5 18 2-M 3 74 Terminal Pin No. Assignment Pin No. 1 2 3 Assignment DC INPUT VDC INPUT V+ FG Pin No. 4 5 Assignment DC OUTPUT +V DC OUTPUT -V Block Diagram fosc : 83KHz I/P EMI FILTER RECTIFIERS & FILTER POWER SWITCHING RECTIFIERS & FILTER +V -V FG O.L.P. PWM CONTROL O.V.P. DETECTION CIRCUIT Derating Curve Static Characteristics(SD-25C-24V) Ta=25 100 SD-25B,C/12,24 32 28 350 300 250 200 150 100 50 80 24 20 16 12 8 60 LOAD (%) SD-25A SD-25B-5 SD-25C-5 40 20 -10 -10 0 0 10 20 30 40 50 45 60 55 (VERTICAL) (HORIZONTAL) 25 30 35 40 45 50 55 60 65 70 72 AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (V) File Name:SD-25-SPEC 2010-07-27 OUTPUT RIPPLE (mVp-p) OUTPUT VOLTAGE (V)
