SD-50A-24

50W Single Output DC-DC Converter Features : 2:1 wide input range SD-50 Protections: Short circuit / Overload / Over voltage 1500VAC I/O isolation Built-in EMI filter, low ripple noise 100% full load burn-in test Fixed switching frequency at 83KHz Low cost High reliability 2 years warranty series SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION VOLTAGE RANGE INPUT EFFICIENCY (Typ.) DC CURRENT OVERLOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS SAFETY & WITHSTAND VOLTAGE ISOLATION RESISTANCE EMC (Note 4) EMC EMISSION EMC IMMUNITY MTBF OTHERS DIMENSION PACKING NOTE SD-50A-5 5V 10A 0 ~ 10A 50W 4.5 ~ 5.5VDC 2.0% 0.5% 0.5% SD-50B-5 SD-50C-5 SD-50A-12 12V 4.2A 0 ~ 4.2A 50.4W 120mVp-p 11 ~ 16VDC 1.0% 0.3% 0.3% SD-50B-12 SD-50C-12 SD-50A-24 24V 2.1A 0 ~ 2.1A 50.4W 150mVp-p 23 ~ 30VDC 1.0% 0.2% 0.2% SD-50B-24 SD-50C-24 RIPPLE & NOISE (max.) Note.2 100mVp-p SETUP, RISE, HOLD UP TIME 2.5s, 50ms, ------ at full load A:9.2 ~ 18VDC 70% 7A/12V 73% B:19 ~ 36VDC 76% C:36 ~ 72VDC 72% 3A/24V 75% 78% 74% 1.5A/48V 80% 83% 105 ~ 150% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed 5.75 ~ 6.75V/10% load 16.8 ~ 20V/10% load 31.5 ~ 37.5V/10% load Protection type : Hiccup mode, recovers automatically after fault condition is removed -10 ~ +60 (Refer to "Derating Curve") 20 ~ 90% RH non-condensing -20 ~ +85 , 10 ~ 95% RH 0.03%/ (0 ~ 50 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes Design refer to LVD I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC / 70% RH I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 Compliance to EN55022 (CISPR22) Class B Compliance to EN61000-4-2,3,4,6,8, EN55024, heavy industry level, criteria A 365.6K hrs min.(SD-50A) 357.5K hrs min.(SD-50B) 368.5K Hrs min.(SD-50C) 159*97*38mm (L*W*H) 0.48Kg; 24pcs/12.7Kg/0.75CUFT MIL-HDBK-217F (25 ) 1. All parameters NOT specially mentioned are measured at 12,24,48VDC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation. 4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.” (as available on http://www.meanwell.com) File Name:SD-50-SPEC 2011-08-23 50W Single Output DC-DC Converter Mechanical Specification 152.5 SD-50 Case No. 901 series Unit:mm 1 9.5 2 3 4 65 3.5 84.5 7 8.2 5 2-M 3 3.5 4.5 24 78 159 6.5 150 97 18.5 Terminal Pin No. Assignment Pin No. 1 2 3 Assignment DC INPUT V+ DC INPUT VFG Pin No. 4 5 Assignment DC OUTPUT -V DC OUTPUT +V 3.5 28.5 38 9 M3 22 117 Block Diagram fosc : 83KHz I/P EMI FILTER RECTIFIERS & FILTER POWER SWITCHING RECTIFIERS & FILTER +V -V FG O.L.P. PWM CONTROL O.V.P. 18 3- 9 Derating Curve 3.5 100 DETECTION CIRCUIT Static Characteristics(SD-50C-24V) SD-50B,C 32 28 350 300 250 200 150 100 50 80 24 20 16 12 8 60 SD-50A 40 20 -10 -10 0 0 10 20 30 40 50 45 60 55 (VERTICAL) (HORIZONTAL) 25 30 35 40 45 50 55 60 65 70 72 AMBIENT TEMPERATURE ( ) INPUT VOLTAGE (V) File Name:SD-50-SPEC 2011-08-23 OUTPUT RIPPLE (mVp-p) OUTPUT VOLTAGE (V) LOAD (%)
